ELDON DPCP121206TE DPCP121206TE ELDON Terminal box, 120x122x56 View larger
Images are for illustrative purposes only. Please refer to data sheet for details

DPCP121206TE ELDON Terminal box, 120x122x56

DPCP121206TE

121206

ELDON

1 Pcs.

Terminal box, 120x122x56 Box for terminals, 120x122x56, transparent cover, without MP, polycarbonate, IP66 Small Polycarbonate Terminal Box, DPCP, 120x122x56, Light Gray, Polycarbonate

Automation > Empty cabinet
Terminal Boxes

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

DPCP121206TE ELDON Terminal box, 120x122x56 functions as a compact polycarbonate terminal housing built to safeguard sensitive wiring junctions and miniature automation devices. Small enclosures of this caliber provide essential insulation and mechanical protection in tight installation spaces.

Pricing, availability, and lead time are confirmed per enquiry through an RFQ.

  • Height: 120 mm
  • Width: 122 mm
  • Depth: 56 mm
  • Max Mounting Depth: 42 mm
  • Material: Polycarbonate
  • Finish: Smooth
  • Color: Light Gray
  • Color Code: RAL 7035
  • EAN: 8713574087781
  • Standard Packaging Quantity: 1.0000
  • Packing Quantity: 1.0000

More info

▲

Features

  • Description: Polycarbonate box, halogen-free, suitable for outdoor use. High UV radiation resistance. Self-extinguishing.
  • Material: Polycarbonate.
  • Gasket: Polyurethane gasket integrated in the box cover.
  • Temperature resistance: -40 °C to +80 °C.
  • Flammability: UL746C 5V.
  • Protection: IP 66, 67 IK 08 (-25 °C … +35 °C).
  • Finish: RAL 7035.
  • Approvals: CE, GOST. For cULus_UL Listed approvals, please contact our sales department.
  • Delivery: Body, cover, cover screws manufactured from stainless steel, mounting screws and cover plugs made of polyamide.
  • Flammability: UL746C 5V
  • Protection: IP 66, 67 IK 08 (-25 °C … +35 °C)
  • Delivery: Body, cover, cover screws manufactured from stainless steel, mounting screws and cover plugs made of polyamide
Atributo del producto Valor
Height120 mm
Width122 mm
Depth56 mm
Max Mounting Depth42 mm
MaterialPolycarbonate
FinishSmooth
ColorLight Gray
Color CodeRAL 7035
EAN8713574087781
Standard Packaging Quantity1.0000
Packing Quantity1.0000

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
