ELDON CUVN05502SS CUVN05502SS ELDON Cooling unit 550W CUVN05502SS View larger
Images are for illustrative purposes only. Please refer to data sheet for details

CUVN05502SS ELDON Cooling unit 550W CUVN05502SS

CUVN05502SS

05502

ELDON

1 Pcs.

Cooling unit 550W CUVN05502SS Cooler 550 W, 230 V, stainless Steel, IP54, NEMA 12 Cooling unit 550W, 230V, Stainless steel, IP54, NEMA 12

Automation > Air conditioner (switchgear cabinet)
General Accessories

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Designed for effective panel climate control, this CUVN05502SS ELDON Cooling unit 550W CUVN05502SS regulates internal cabinet temperatures to safeguard sensitive electrical systems. Industrial cooling units remove accumulated heat loads, preventing unexpected downtime in manufacturing operations. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Height: 642mm
  • Width: 313mm
  • Depth: 223mm
  • Material: Stainless Steel
  • Finish: Plated
  • Phase Quantity: 1
  • Frequency: 50/60 HzHz
  • UPC: 783510462376
  • EAN: 8713574211094
  • Standard Packaging Quantity: 1
  • Packing Quantity: 1
  • Operating voltage AC 50 Hz (EF008206): 230.00 V
  • Operating voltage AC 60 Hz (EF008207): 230.00 V
  • Voltage type (EF000187): AC
  • With temperature control (EF000745): Yes
  • Function master/slave (EF007183): No

More info

▲

Features

  • Vertical cooling unit with smart energy management, available in a wide range of sizes for different cooling capacities, with a IP 54 protection degree
  • Customers can choose the cooling unit that meets their requirements the most, removing any extra costs due to oversizing Smart energy management reduces the cooling units energy consumption by up to 23%
  • The efficient cooling unit allows customers to optimise the enclosure's design ensuring that the correct cooling unit is chosen and it hasn't been over specified
  • The smart energy management and ease of installation will reduce both operational and installation costs
  • To minimise how much energy the cooling unit consumes, it is recommended to install the door switch, DSW01
  • Once installed, the door switch will turn the cooling unit off, once the door is opened
  • Voltage: 200-235 V
  • Alternating current frequency: 50~60 Hz
  • Power of the fan: 22 Watt
  • Consumption current: 0.28A / 0.56A
  • Air circulation: 4.4 / 8.8 m³/min
  • Measurement limits: -50 ºC ... +125 ºC
  • Measurement accuracy: +/-0.5ºC
  • Working temperature: 0...+50ºC
  • Relative air humidity (air temp. +35C): 80%
  • Noise level: 35 decibel
  • Lifetime: 30.000 hours
  • Switch: No
  • Thermostat: Yes
  • Pack quantity: 1 unit including power cable (1.5 m) with Shuko plug and sensor cable (1.2 m); version with 4 fans is supplied with a depth fixing bracket
Atributo del producto Valor
Height642mm
Width313mm
Depth223mm
MaterialStainless Steel
FinishPlated
Phase Quantity1
Frequency50/60 HzHz
UPC783510462376
EAN8713574211094
Standard Packaging Quantity1
Packing Quantity1

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
