CUVN03602 ELDON Cooling unit 360W CUVN03602
CUVN03602
03602
ELDON
1 Pcs.
Automation > Air conditioner (switchgear cabinet)
General Accessories
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
CUVN03602 ELDON Cooling unit 360W CUVN03602 operates as a compact climate control device engineered to remove moderate heat loads from smaller electrical control panels. Automation technicians install panel coolers to protect sensitive PLCs and instrumentation from thermal degradation in enclosed spaces. Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Height: 443mm
- Width: 324mm
- Depth: 206mm
- Material: Steel
- Finish: Plated
- Phase Quantity: 1
- Frequency: 50/60 HzHz
- UPC: 783510462284
- EAN: 8713574210875
- Standard Packaging Quantity: 1
- Packing Quantity: 1
- Operating voltage AC 50 Hz (EF008206): 230.00 V
- Operating voltage AC 60 Hz (EF008207): 230.00 V
- Voltage type (EF000187): AC
- With temperature control (EF000745): Yes
- Function master/slave (EF007183): No
More info
▲Features
- Vertical cooling unit with smart energy management, available in a wide range of sizes for different cooling capacities, with a IP 54 protection degree
- Customers can choose the cooling unit that meets their requirements the most, removing any extra costs due to oversizing Smart energy management reduces the cooling units energy consumption by up to 23%
- The efficient cooling unit allows customers to optimise the enclosure's design ensuring that the correct cooling unit is chosen and it hasn't been over specified
- The smart energy management and ease of installation will reduce both operational and installation costs
- To minimise how much energy the cooling unit consumes, it is recommended to install the door switch, DSW01
- Once installed, the door switch will turn the cooling unit off, once the door is opened
- Voltage: 200-235 V
- Alternating current frequency: 50~60 Hz
- Power of the fan: 22 Watt
- Consumption current: 0.28A / 0.56A
- Air circulation: 4.4 / 8.8 m³/min
- Measurement limits: -50 ºC ... +125 ºC
- Measurement accuracy: +/-0.5ºC
- Working temperature: 0...+50ºC
- Relative air humidity (air temp. +35C): 80%
- Noise level: 35 decibel
- Lifetime: 30.000 hours
- Switch: No
- Thermostat: Yes
- Pack quantity: 1 unit including power cable (1.5 m) with Shuko plug and sensor cable (1.2 m); version with 4 fans is supplied with a depth fixing bracket
| Atributo del producto | Valor |
|---|---|
| Height | 443mm |
| Width | 324mm |
| Depth | 206mm |
| Material | Steel |
| Finish | Plated |
| Phase Quantity | 1 |
| Frequency | 50/60 HzHz |
| UPC | 783510462284 |
| EAN | 8713574210875 |
| Standard Packaging Quantity | 1 |
| Packing Quantity | 1 |
