ELDON CUVN10502 CUVN10502 ELDON Cooling unit 1050W CUVN10502 View larger
Images are for illustrative purposes only. Please refer to data sheet for details

CUVN10502 ELDON Cooling unit 1050W CUVN10502

CUVN10502

10502

ELDON

1 Pcs.

Cooling unit 1050W CUVN10502 Cooler 1050 W, 230 V, sheet steel, IP54, NEMA 12 Cooling unit 1050W, 230V, Mild steel, IP54, NEMA 12

Automation > Air conditioner (switchgear cabinet)
General Accessories

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

CUVN10502 ELDON Cooling unit 1050W CUVN10502 operates as an internal thermal management assembly designed to regulate ambient heat within electrical control panels. Industrial automation engineers deploy cabinet cooling units to extend the service life of sensitive electronic components housed in standard enclosures. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Height: 912 mm
  • Width: 410 mm
  • Depth: 248 mm
  • Material: Mild Steel
  • Finish: Plated
  • Color: Unpainted
  • Phase Quantity: 1
  • Frequency: 50/60 Hz
  • UPC: 783510462451
  • EAN: 8713574210943
  • Standard Packaging Quantity: 1.0000
  • Packing Quantity: 1.0000
  • Operating voltage AC 50 Hz (EF008206): 230.00 V
  • Operating voltage AC 60 Hz (EF008207): 230.00 V
  • Operating voltage DC (EF008208): None V
  • Voltage type (EF000187): AC

More info

▲

Features

  • Vertical cooling unit with smart energy management, available in a wide range of sizes for different cooling capacities, with a IP 54 protection degree
  • Customers can choose the cooling unit that meets their requirements the most, removing any extra costs due to oversizing Smart energy management reduces the cooling units energy consumption by up to 23%
  • The efficient cooling unit allows customers to optimise the enclosure's design ensuring that the correct cooling unit is chosen and it hasn't been over specified
  • The smart energy management and ease of installation will reduce both operational and installation costs
  • To minimise how much energy the cooling unit consumes, it is recommended to install the door switch, DSW01
  • Once installed, the door switch will turn the cooling unit off, once the door is opened
  • Voltage: 200-235 V
  • Alternating current frequency: 50~60 Hz
  • Power of the fan: 22 Watt
  • Consumption current: 0.28A / 0.56A
  • Air circulation: 4.4 / 8.8 m³/min
  • Measurement limits: -50 ºC ... +125 ºC
  • Measurement accuracy: +/-0.5ºC
  • Working temperature: 0...+50ºC
  • Relative air humidity (air temp. +35C): 80%
  • Noise level: 35 decibel
  • Lifetime: 30.000 hours
  • Switch: No
  • Thermostat: Yes
  • Pack quantity: 1 unit including power cable (1.5 m) with Shuko plug and sensor cable (1.2 m); version with 4 fans is supplied with a depth fixing bracket
Atributo del producto Valor
Height912 mm
Width410 mm
Depth248 mm
MaterialMild Steel
FinishPlated
ColorUnpainted
Phase Quantity1
Frequency50/60 Hz
UPC783510462451
EAN8713574210943
Standard Packaging Quantity1.0000
Packing Quantity1.0000

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
