View larger
Images are for illustrative purposes only. Please refer to data sheet for details
XTSZPTCV 172729 Y7-172729 EATON ELECTRIC Side Panel for corner
XTSZPTCV
172729
Y7-172729
EATON - MOELLER
1 Pcs.
Side Panel for corner
XTSZPTCV
Eaton xEnergy Main LV systems LV switchgear. Connection top plate, ventilated, grey
Connection top plate, ventilated, grey
Automation > Top-/floor cover element (enclosure/switchgear cabinet)
Enclosures
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲General specifications
Product Name
Eaton xEnergy Main LV switchgear
Catalog Number
172729
Model Code
XTSZPTCV
EAN
4015081692750
Product Length/Depth
682 mm
Product Height
78 mm
Product Width
208 mm
Product Weight
5.787 kg
Compliances
RoHS conform
Product specifications
Fitted with:
De-aeration
Surface finishing
Powder coating
Color
Gray
RAL-number
7035
Suitable for enclosure building length/depth
700 mm
Suitable for enclosure building width
0 mm
Material
Steel
Suitable for
Roof planking
Bottom planking
Bottom planking
| Feature Name | Feature Value |
|---|---|
| Suitable for roof planking (EF009584) | Yes |
| Suitable for bottom planking (EF009585) | Yes |
| Width (EF000008) | 208 mm |
| Height (EF000040) | 78 mm |
| Depth (EF000049) | 682 mm |
| Suitable for enclosure building width (EF000326) | 0 mm |
| Suitable for enclosure building depth (EF000327) | 700 mm |
| Material (EF002169) | Steel |
| Surface finishing (EF006569) | Powder coated |
| Colour (EF000007) | Grey |
| RAL-number (EF000116) | 7035 |
| With de-aeration (EF001161) | Yes |
| Suitable for outdoor set-up (EF005774) | No |
| With cable entry (EF000325) | No |
