View larger
Images are for illustrative purposes only. Please refer to data sheet for details
XSPTU08A 178053 Y7-178053 EATON ELECTRIC Top Panel, Alu, D 800mm
XSPTU08A
178053
Y7-178053
EATON - MOELLER
1 Pcs.
Top Panel, Alu, D=800mm
XSPTU08A
Eaton xEnergy Main LV systems LV switchgear. Top panel, Alu, D=800mm
Aluminum top plate, depth 800 mm, untreated, full
Automation > Top-/floor cover element (enclosure/switchgear cabinet)
Enclosures
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲General specifications
Product Name
Eaton xEnergy Main LV switchgear
Catalog Number
178053
Model Code
XSPTU08A
EAN
4015081733286
Product Length/Depth
662 mm
Product Height
76.5 mm
Product Width
172 mm
Product Weight
1.94 kg
Compliances
RoHS conform
Product specifications
Fitted with:
Cable entry
Surface finishing
Primed
Color
Gray
RAL-number
0
Suitable for enclosure building length/depth
800 mm
Suitable for enclosure building width
800 mm
Material
Aluminum
Suitable for
Roof planking
Bottom planking
Bottom planking
| Feature Name | Feature Value |
|---|---|
| Suitable for roof planking (EF009584) | Yes |
| Suitable for bottom planking (EF009585) | Yes |
| Width (EF000008) | 172 mm |
| Height (EF000040) | 76.5 mm |
| Depth (EF000049) | 662 mm |
| Suitable for enclosure building width (EF000326) | 800 mm |
| Suitable for enclosure building depth (EF000327) | 800 mm |
| Material (EF002169) | Aluminium |
| Surface finishing (EF006569) | Primed |
| Colour (EF000007) | Grey |
| RAL-number (EF000116) | 0 |
| With de-aeration (EF001161) | No |
| Suitable for outdoor set-up (EF005774) | No |
| With cable entry (EF000325) | Yes |
