EATON - MOELLER XPRCC2006 XPRCC2006 184642 Y7-184642 EATON ELECTRIC xEnergy No Description View larger
Images are for illustrative purposes only. Please refer to data sheet for details

XPRCC2006 184642 Y7-184642 EATON ELECTRIC xEnergy No Description

XPRCC2006

184642

Y7-184642

EATON - MOELLER

1 Pcs.

xEnergy - No Description XPRCC2006 Separating partition, sideways, for cable connection area, depth 600mm Side partition for cable connection area. Depth: 600 mm; in the case of British Standard applications, partitioning into individual terminal areas, requiring a separate cable section

Automation > Divider panel (switchgear cabinet)
Enclosures

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲
Separating partition, sideways, for cable connection area, depth 600mm
Side partition for cable connection area. Depth: 600 mm; in the case of British Standard applications, partitioning into individual terminal areas, requiring a separate cable section

Technical data ETIM 7.0

Cabinet enclosures (EG000011) / Divider panel (switchgear cabinet) (EC002525)
Electric engineering, automation, process control engineering / Electrical cabinet, housing, rack / Panel (electrical cabinet) / Divider panel (electrical cabinet) ([email protected] [AKE424014])
Modular spacing
25 mm
Suitable for enclosure building width
0 mm
Suitable for enclosure building depth
600 mm
Width
0 mm
Height
0 mm
Material
Steel
Surface finishing
Galvanized
Colour
Grey
RAL-number
0
With cable entry
No
Number of height units
0
With lock
No
Construction type
Individual part
For internal separation form 2a
No
For internal separation form 2b
No
For internal separation form 3a
No
For internal separation form 3b
No
For internal separation form 4a
No
For internal separation form 4b
Yes

ETIM for 184642 Cabinets and enclosures (EC002525)
Feature Name Feature Value
Modular spacing (EF000394) 25 mm
Suitable for enclosure building width (EF000326) 0 mm
Suitable for enclosure building depth (EF000327) 600 mm
Width (EF000008) 19 mm
Height (EF000040) 1905 mm
Material (EF002169) Steel
Surface finishing (EF006569) Galvanised
Colour (EF000007) Grey
RAL-number (EF000116) 0
With cable entry (EF000325) No
Number of height units (EF003561) 0
With lock (EF006306) No
Construction type (EF000767) Individual part
For internal separation form 2a (EF009586) No
For internal separation form 2b (EF009587) No
For internal separation form 3a (EF009588) No
For internal separation form 3b (EF009589) No
For internal separation form 4a (EF009590) No
For internal separation form 4b (EF009591) Yes
