EATON - MOELLER XPBM2006 XPBM2006 102053 Y7-102053 EATON ELECTRIC Partition, devices-/devices- area, form 2b, HxW 2000x600mm View larger
Images are for illustrative purposes only. Please refer to data sheet for details

XPBM2006 102053 Y7-102053 EATON ELECTRIC Partition, devices-/devices- area, form 2b, HxW 2000x600mm

XPBM2006

102053

Y7-102053

EATON - MOELLER

1 Pcs.

Partition, devices-/devices- area, form 2b, HxW=2000x600mm XPBM2006 Partition with a section width of 600 mm for fully partitioning the main busbars (in the case of rear busbars) across the entire section height. Incl. all screw accessories.

Automation > Divider panel (switchgear cabinet)
Enclosures

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

An Eaton Moeller partition, devices-/devices- area, form 2b, HxW 2000x600mm, part number XPBM2006, establishes reliable form 2b internal separation between device compartments in industrial switchboards. This assembly kit is deployed to enhance operator safety by isolating active electrical equipment areas.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Modular spacing (EF000394): 12.5 mm
  • Suitable for enclosure building width (EF000326): 600 mm
  • Suitable for enclosure building depth (EF000327): 0 mm
  • Width (EF000008): 600 mm
  • Height (EF000040): 40 mm
  • Material (EF002169): Steel
  • Surface finishing (EF006569): Galvanised
  • Colour (EF000007): Stainless steel
  • RAL-number (EF000116): 0
  • With cable entry (EF000325): No
  • Number of height units (EF003561): 0
  • With lock (EF006306): No
  • Construction type (EF000767): Assembly kit
  • For internal separation form 2a (EF009586): Yes
  • For internal separation form 2b (EF009587): Yes
  • For internal separation form 3a (EF009588): Yes

More info

▲

General specifications

Product Name
Eaton xEnergy Main LV switchgear
Catalog Number
102053
Model Code
XPBM2006
EAN
4015081022014
Product Length/Depth
1950 mm
Product Height
40 mm
Product Width
600 mm
Product Weight
9.8 kg
Compliances
RoHS conform

Product specifications

Construction type
Assembly kit
Surface finishing
Galvanized
Color
Stainless steel
Modular spacing
12.5 mm
Number of height units
0
RAL-number
0
Suitable for enclosure building length/depth
0 mm
Suitable for enclosure building width
600 mm
Material
Steel
Suitable for
Internal separation form 4b
Internal separation form 3b
Internal separation form 2b
Internal separation form 3a
Internal separation form 2a
Internal separation form 4a
