EATON - MOELLER MMX12AA4D8F0-0 MMX12AA4D8F0-0 121367 EATON ELECTRIC Variable frequency drives, 1p, 230 V, 4.8A, 1.1kW View larger
Images are for illustrative purposes only. Please refer to data sheet for details

MMX12AA4D8F0-0 121367 EATON ELECTRIC Variable frequency drives, 1p, 230 V, 4.8A, 1.1kW

MMX12AA4D8F0-0

121367

EATON - MOELLER

1 Pcs.

Variable frequency drives, 1p, 230 V, 4.8A, 1.1kW Mains voltage (50/60Hz): ULN = 208 (-15%) - 240 (+10%) V, Degree of Protection: IP20/NEMA 0, Fitted with: Fan (internal, temperature controlled), Frame size: FS2

Automation > Frequency converter less than 1 kV

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Providing efficient conversion from single-phase supply to three-phase motor output, the Eaton Moeller MMX12AA4D8F0-0 variable frequency drive enhances operational flexibility. These units are frequently deployed in commercial and light industrial applications to control pumps, fans, and small conveyors. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Mains voltage (EF006780): 177 V
  • Mains frequency (EF006783): 50/60 Hz
  • Number of phases input (EF007117): 1
  • Number of phases output (EF006998): 3
  • Max. output frequency (EF007350): 320 Hz
  • Max. output voltage (EF009560): 230 V
  • Nominal output current I2N (EF009561): 4.8 A
  • Relative symmetric net frequency tolerance (EF007454): 0 %
  • With control element (EF001538): Yes
  • Application in industrial area permitted (EF007294): Yes
  • Supporting protocol for TCP/IP (EF003050): No
  • Supporting protocol for PROFIBUS (EF003052): No
  • Supporting protocol for CAN (EF003053): No
  • Supporting protocol for INTERBUS (EF003054): No
  • Supporting protocol for ASI (EF003051): No
  • Supporting protocol for KNX (EF003055): No
