NZM1-XUL600AC 259477 Y7-259477 EATON ELECTRIC Undervoltage release, 600VAC
NZM1-XUL600AC
259477
Y7-259477
EATON - MOELLER
1 Pcs.
Automation > Under voltage coil
Circuit Breakers NZM
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
An Eaton Moeller NZM1-XUL600AC undervoltage release provides automatic circuit interruption when voltage supplies fail or drop dangerously low, preventing uncontrolled re-energization. Facilities rely on these internal releases to protect industrial machinery and maintain electrical safety standards.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Rated control supply voltage AC 50 Hz (EF003978): 600 V
- Rated control supply voltage AC 60 Hz (EF003979): 600 V
- Rated control supply voltage DC (EF003980): 0 V
- Voltage type for actuating (EF008242): AC
- Type of electric connection (EF003961): Screw connection
- Number of contacts as normally open contact (EF008256): 0
- Number of contacts as normally closed contact (EF008255): 0
- Number of contacts as change-over contact (EF008257): 0
- Delayed (EF001541): No
- Suitable for power circuit breaker (EF005863): No
- Suitable for off-load switch (EF001543): Yes
- Suitable for motor safety switch (EF005826): No
- Suitable for overload relay (EF001545): No
More info
▲General specifications
IEC
RoHS conform
UL (File No. E140305)
CSA (Class No. 1437-01)
UL489
CSA (File No. 22086)
CE marking
UL listed
UL (Category Control Number DIHS)
IEC60947
CSA-C22.2 No. 5-09
Product specifications
0.75 mm² - 2.5 mm² (2x) at shunt release with ferrule
18 - 14 AWG (2x) for undervoltage releases, off-delayed
0.75 mm² - 2.5 mm² (2x) for undervoltage releases, off-delayed with ferrule
18 - 14 AWG (1x) for undervoltage releases, off-delayed
18 - 14 AWG (1x) at shunt release
0.75 mm² - 2.5 mm² (1x) for undervoltage releases, off-delayed with ferrule
18 - 14 AWG (2x) at shunt release
1.5 VA (sealing AC)
