View larger
Images are for illustrative purposes only. Please refer to data sheet for details
+IZM-UVR48DC 122750 EATON ELECTRIC Undervoltage release, 48VDC
+IZM-UVR48DC
122750
EATON - MOELLER
1 Pcs.
Undervoltage release, 48VDC
Undervoltage release, For use with: IZM20, 32, 40, 63…, IN20, 32,40, 63…, If ordered separately a secondary terminal unit IZM‐SEC‐… is necessary for connection. Order separately if required. Terminal assignment page 71
Automation > Under voltage coil
Circuit Breakers IZM
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲Undervoltage release, 48VDC
Undervoltage release, For use with: IZM20, 32, 40, 63…, IN20, 32,40, 63…, If ordered separately a secondary terminal unit IZM‐SEC‐… is necessary for connection. Order separately if required. Terminal assignment page 71
Delivery program
Accessories
Voltage release
Accessories
Undervoltage release
For use with
IZM20, 32, 40, 63…
IN20, 32,40, 63…
IN20, 32,40, 63…
Instructions
If ordered separately a secondary terminal unit IZM‐SEC‐… is necessary for connection. Order separately if required. Terminal assignment page 71
Technical data
Rated control voltage [Us]
DC [Us]
48 V
Power consumption
DC
18 (pick-up 275) W
Circuit-breaker response time at Us
70 ms
Operating range
Drop-out voltageAC operated, 50/60 Hz, pick-up [Drop-out]
According to the IEC standard x Uc
Pick-up voltage [Pick-up]
According to the IEC standard x Uc
Design verification as per IEC/EN 61439
Operating ambient temperature min.
-25 °C
Operating ambient temperature max.
+70 °C
| Feature Name | Feature Value |
|---|---|
| Delayed (EF001541) | No |
| Suitable for power circuit breaker (EF005863) | No |
| Suitable for off-load switch (EF001543) | No |
| Suitable for motor safety switch (EF005826) | No |
| Suitable for overload relay (EF001545) | No |
