NZM1-XU220-250DC 259460 Y7-259460 EATON ELECTRIC Undervoltage release, 220-250VDC
NZM1-XU220-250DC
259460
Y7-259460
EATON - MOELLER
1 Pcs.
Automation > Under voltage coil
Circuit Breakers NZM
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
An Eaton Moeller NZM1-XU220-250DC undervoltage release is designed to drop out and actuate a trip mechanism when the control circuit voltage falls below established limits. These electrical accessories help protect industrial machinery from erratic operation during supply voltage drops.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Rated control supply voltage AC 50 Hz (EF003978): 0 V
- Rated control supply voltage AC 60 Hz (EF003979): 0 V
- Rated control supply voltage DC (EF003980): 220 V
- Voltage type for actuating (EF008242): AC
- Type of electric connection (EF003961): Screw connection
- Number of contacts as normally open contact (EF008256): 0
- Number of contacts as normally closed contact (EF008255): 0
- Number of contacts as change-over contact (EF008257): 0
- Delayed (EF001541): false
- Suitable for power circuit breaker (EF005863): false
- Suitable for off-load switch (EF001543): true
- Suitable for motor safety switch (EF005826): false
- Suitable for overload relay (EF001545): false
More info
▲General specifications
IEC
RoHS conform
IEC60947
CSA certified
CSA (Class No. 1437-01)
CE marking
UL489
CSA (File No. 22086)
UL (Category Control Number DIHS)
UL listed
CSA-C22.2 No. 5-09
Product specifications
0.75 mm² - 2.5 mm² (2x) for undervoltage releases, off-delayed with ferrule
18 - 14 AWG (1x) for undervoltage releases, off-delayed
0.75 mm² - 2.5 mm² (1x) for undervoltage releases, off-delayed with ferrule
0.75 mm² - 2.5 mm² (2x) at shunt release with ferrule
18 - 14 AWG (2x) at shunt release
18 - 14 AWG (2x) for undervoltage releases, off-delayed
18 - 14 AWG (1x) at shunt release
1.5 VA (sealing AC)
220 V DC
