EATON - MOELLER T5B-5-15892/E T5B-5-15892/E 091956 Y7-91956 EATON ELECTRIC Star-delta switches, Contacts: 10, 63 A, front plate: B 0-Y-D, .. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

T5B-5-15892/E 091956 Y7-91956 EATON ELECTRIC Star-delta switches, Contacts: 10, 63 A, front plate: B 0-Y-D, ..

T5B-5-15892/E

091956

Y7-91956

EATON - MOELLER

1 Pcs.

Star-delta switches, Contacts: 10, 63 A, front plate: B>0-Y-D, 60 °, maintained, flush mounting, SOND 29 Switch Star-Triangle; 10-pole; 63; rating Plate: B>0-And-D; 60 °; Interlock; recessed Mounting; SOND 29 Eaton Moeller® series T5B Star-delta switches, T5B, 63 A, flush mounting, 5 contact unit(s), Contacts: 10, 60 °, maintained, With 0 (Off) position, With spring-return to 0, B>0-Y-D, SOND 29, Design number 15892 Star-delta switch, Product range: Control switches, Part group reference: T5B, with black thumb grip and front plate, Notes: SOND 29, Contacts: 10, Degree of Protection: Front IP65, Design: flush mounting, Switching angle: 60 °, Switching performance: maintained, With 0 (Off) position, With spring-return to 0, front plate: B>0-Y-D, Motor rating AC-23A, 50 - 60 Hz 400 V: P = 30 kW, Rated uninterrupted current: Iu = 63 A, 5 contact unit(s), Standards: IEC/EN 60947, VDE 0660, IEC/EN 60204, CSA, UL, Switch-disconnector according to IEC/EN 60947-3

Automation > Off-load switch
Disconnectors and Cam Switches

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

The Eaton Moeller T5B-5-15892/E is a star-delta switch built to manage the reduced-voltage startup of heavy induction motors in industrial plants. These manual control switches smoothly transition motor windings from star to delta configuration to limit inrush current. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Model (EF000010): Star-delta switch
  • Number of poles (EF001391): 3
  • With zero (off) position (EF001416): Yes
  • With retraction in 0-position (EF002428): Yes
  • Rated permanent current Iu (EF001389): 63 A
  • Rated operation current Ie at AC-3, 400 V (EF001392): 41 A
  • Rated operation power at AC-3, 400 V (EF001364): 37 kW
  • Degree of protection (IP), front side (EF003118): IP65
  • Degree of protection (NEMA), front side (EF011961): 12
  • Suitable for floor mounting (EF007243): No
  • Suitable for front mounting (EF007246): Yes
  • Suitable for distribution board installation (EF007262): No
  • Suitable for intermediate mounting (EF007264): No
  • Complete device in housing (EF007317): No
  • Housing material (EF001596): Plastic
  • Type of control element (EF006976): Short thumb-grip

More info

▲

General specifications

Product Name
Eaton Moeller® series T5B Star-delta switch
Catalog Number
091956
Model Code
T5B-5-15892/E
EAN
4015080919568
Product Length/Depth
157 mm
Product Height
88 mm
Product Width
88 mm
Product Weight
0.86 kg
Certifications
CSA Class No.: 3211-07
UL
UL 60947-4-1
IEC/EN 60947-3
CSA-C22.2 No. 94
UL Category Control No.: NLRV
CSA File No.: 012528
CSA-C22.2 No. 60947-4-1-14
VDE 0660
CE
IEC/EN 60204
IEC/EN 60947
UL File No.: E36332
CSA
Catalog Notes
Rated Short-time Withstand Current (Icw) for a time of 1 second

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
