EATON - MOELLER T5-5-8361/Z T5-5-8361/Z 095278 Y7-95278 EATON ELECTRIC Switch, Toggle Contacts: 10 100 rating Plate: 1-0-2 60 ° Interloc.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

T5-5-8361/Z 095278 Y7-95278 EATON ELECTRIC Switch, Toggle Contacts: 10 100 rating Plate: 1-0-2 60 ° Interloc..

T5-5-8361/Z

095278

Y7-95278

EATON - MOELLER

1 Pcs.

Switch, Toggle; Contacts: 10; 100; rating Plate: 1-0-2; 60 °; Interlock; Mounting bottom panel Switch Switch 10 poles 100 A Indicator plate: 1-0-2 60° Eaton Moeller® series T5 Changeoverswitches, T5, 100 A, rear mounting, 5 contact unit(s), Contacts: 10, 60 °, maintained, With 0 (Off) position, 1-0-2, Design number 8361 Changeover switch, Product range: Control switches, Part group reference: T5, with black thumb grip and front plate, Contacts: 10, Degree of Protection: Front IP65, Design: rear mounting, Switching angle: 60 °, Switching performance: maintained, With 0 (Off) position, front plate: 1-0-2, Motor rating AC-23A, 50 - 60 Hz 400 V: P = 55 kW, Rated uninterrupted current: Iu = 100 A, 5 contact unit(s), Standards: IEC/EN 60947, VDE 0660, IEC/EN 60204, Switch-disconnector according to IEC/EN 60947-3

Automation > Off-load switch
Disconnectors and Cam Switches

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Eaton Moeller T5-5-8361/Z is a toggle switch used for manually directing electrical currents and managing power routing across complex industrial control circuits.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Model (EF000010): Reverser
  • Number of poles (EF001391): 5
  • With zero (off) position (EF001416): Yes
  • With retraction in 0-position (EF002428): No
  • Rated permanent current Iu (EF001389): 100 A
  • Rated operation current Ie at AC-3, 400 V (EF001392): 55 A
  • Rated operation power at AC-3, 400 V (EF001364): 30 kW
  • Degree of protection (IP), front side (EF003118): IP65
  • Degree of protection (NEMA), front side (EF011961): 12
  • Suitable for floor mounting (EF007243): Yes
  • Suitable for front mounting (EF007246): No
  • Suitable for distribution board installation (EF007262): No
  • Suitable for intermediate mounting (EF007264): Yes
  • Complete device in housing (EF007317): No
  • Housing material (EF001596): Plastic
  • Type of control element (EF006976): Short thumb-grip

More info

▲

General specifications

Product Name
Eaton Moeller® series T5 Changeover switch
Catalog Number
095278
Model Code
T5-5-8361/Z
EAN
4015080952787
Product Length/Depth
198 mm
Product Height
88 mm
Product Width
88 mm
Product Weight
0.893 kg
Certifications
VDE 0660
IEC/EN 60947
IEC/EN 60204
IEC/EN 60947-3
Catalog Notes
Rated Short-time Withstand Current (Icw) for a time of 1 second
