EATON - MOELLER T0-5-8531/Z T0-5-8531/Z 015205 Y7-15205 EATON ELECTRIC Changeoverswitches, Contacts: 10, 20 A, front plate: Phase-0-Erde.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

T0-5-8531/Z 015205 Y7-15205 EATON ELECTRIC Changeoverswitches, Contacts: 10, 20 A, front plate: Phase-0-Erde..

T0-5-8531/Z

015205

Y7-15205

EATON - MOELLER

1 Pcs.

Changeoverswitches, Contacts: 10, 20 A, front plate: Phase-0-Erde, 45 °, maintained, rear mounting Switch 10-pole 20 A Indicator plate: Phase-0-Erde Eaton Moeller® series T0 Changeoverswitches, T0, 20 A, rear mounting, 5 contact unit(s), Contacts: 10, 45 °, maintained, With 0 (Off) position, Phase-0-Erde, Design number 8531 Changeover switch, Product range: Control switches, Standards: IEC/EN 60947, VDE 0660, IEC/EN 60204, CSA, UL, Switch-disconnector according to IEC/EN 60947-3, Part group reference: T0, with black thumb grip and front plate, Contacts: 10, Degree of Protection: Front IP65, Design: rear mounting, Switching angle: 45 °, Switching performance: maintained, With 0 (Off) position, 5 contact unit(s), Rated uninterrupted current: Iu= 20 A, front plate: Phase-0-Erde

Automation > Control switch
Disconnectors and Cam Switches

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Designed by Eaton Moeller, the T0-5-8531/Z changeoverswitch serves as a robust manual interface for routing electrical signals across complex industrial machinery and power distribution setups. Operators rely on such multi-position switches to safely manage circuit selections and operational modes in factory automation environments.

Pricing, availability, and lead time are confirmed per enquiry through an RFQ.

  • Type of switch (EF003496): Reverser
  • Number of poles (EF001391): 6
  • Max. rated operation voltage Ue AC (EF007355): 690 V
  • Rated permanent current Iu (EF001389): 20 A
  • Number of switch positions (EF000231): 3
  • With zero (off) position (EF001416): Yes
  • With retraction in 0-position (EF002428): No
  • Device construction (EF008240): Built-in device
  • Width in number of modular spacings (EF002950): 0
  • Suitable for floor mounting (EF007243): Yes
  • Suitable for front mounting (EF007246): No
  • Suitable for distribution board installation (EF007262): No
  • Suitable for intermediate mounting (EF007264): Yes
  • Complete device in housing (EF007317): No
  • Type of control element (EF006976): Toggle
  • Front shield size (EF007176): 48x48 mm

More info

▲

General specifications

Product Name
Eaton Moeller® series T0 Changeover switch
Catalog Number
015205
Model Code
T0-5-8531/Z
EAN
4015080152057
Product Length/Depth
156 mm
Product Height
48 mm
Product Width
48 mm
Product Weight
0.211 kg
Certifications
IEC/EN 60204
CSA Class No.: 3211-05
CSA-C22.2 No. 60947-4-1-14
CSA-C22.2 No. 94
IEC/EN 60947
UL
VDE 0660
UL File No.: E36332
CE
IEC/EN 60947-3
UL 60947-4-1
UL Category Control No.: NLRV
CSA File No.: 012528
CSA
Catalog Notes
Rated Short-time Withstand Current (Icw) for a time of 1 second

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
