EATON - MOELLER IZM-SR24DC IZM-SR24DC 122942 Y7-122942 EATON ELECTRIC Spring release, 24VDC View larger
Images are for illustrative purposes only. Please refer to data sheet for details

IZM-SR24DC 122942 Y7-122942 EATON ELECTRIC Spring release, 24VDC

IZM-SR24DC

122942

Y7-122942

EATON - MOELLER

1 Pcs.

Spring release, 24VDC IZM-SR24DC Closing release, Accessories, 4000 to 6300 A, Voltage release, Closing releases, Standard/Approval: IEC, A closing release can be combined with a shunt release and an undervoltage release or with an undervoltage release or with a second shunt release., Rated control voltage: Us 24 DC V, For use with: IZM20, 32, 40, 63…, IN20, 32,40, 63…, If ordered separately a secondary terminal unit IZM‐SEC‐… is necessary for connection. Order separately if required. Terminal assignment page 71

Automation > Shunt release (for power circuit breaker)
Circuit Breakers IZM

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

A spring release mechanism is an internal accessory utilized in heavy electrical breakers to store and release mechanical energy for rapid closing operations. This Eaton Moeller IZM-SR24DC component ensures reliable actuation within automated industrial power distribution environments.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Suitable for power circuit breaker (EF005863): No
  • Suitable for off-load switch (EF001543): No
  • Suitable for motor safety switch (EF005826): No
  • Suitable for overload relay (EF001545): No

More info

▲
Spring release, 24VDC
Eaton Catalog No.
2A10704G01
Closing release, Accessories, 4000 to 6300 A, Voltage release, Closing releases, Standard/Approval: IEC, A closing release can be combined with a shunt release and an undervoltage release or with an undervoltage release or with a second shunt release., Rated control voltage: Us 24 DC V, For use with: IZM20, 32, 40, 63…, IN20, 32,40, 63…, If ordered separately a secondary terminal unit IZM‐SEC‐… is necessary for connection. Order separately if required. Terminal assignment page 71
[

Delivery program

Product range
Accessories
Current Range
4000 to 6300 A
Accessories
Voltage release
Accessories
Closing releases
Standard/Approval
IEC
A closing release can be combined with a shunt release and an undervoltage release or with an undervoltage release or with a second shunt release.
Rated control voltage [Us]
24 DC V
For use with
IZM20, 32, 40, 63…
IN20, 32,40, 63…
Instructions
If ordered separately a secondary terminal unit IZM‐SEC‐… is necessary for connection. Order separately if required. Terminal assignment page 71
,

Technical data

Rated control voltage [Us]
DC [Us]
24 V
Power consumption
DC
(pick-up 250) W
Circuit-breaker response time at Us
40 ms
Operating range
Pick-up voltage [Pick-up]
According to the IEC standard x Uc
,

Design verification as per IEC/EN 61439

Operating ambient temperature min.
-25 °C
Operating ambient temperature max.
+70 °C
]

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
