20.610.32-350 221161 EATON ELECTRIC Semiconductor fuse, superfast, 350A
20.610.32-350
221161
EATON - MOELLER
1 Pcs.
Semiconductor fuse, superfast, 350A
Superfast semiconductor fuse for achieving the type of coordination 2 with soft starters. In case of a short-circuit, the soft starter is effectively protected against damage and can be reused after replacing the fuse.
Automation > Low Voltage HRC fuse
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲Delivery programme
Product range | Accessories | ||
Accessories | Fuses | ||
Rated device current | A | 350 | |
Maximum power loss | Pv | W | 61 |
Inside micrometer | mm | 80 | |
For use with | DS6-340-75K-MX DS7-34…SX135N0-… DM4-340-55K DM4-340-75K | ||
For use with | Soft starters |
Technical data ETIM 6.0(Show features)(Hide features)
| Circuit breakers and fuses (EG000020) / Low Voltage HRC fuse (EC000055) | |||
| Electric engineering, automation, process control engineering / Electrical installation, device / Safety fuse inserts / Low-Voltage HRC fuse ([email protected] [AFZ800012]) | |||
Construction size | NH1 | ||
Nominal rated current | A | 350 | |
Nominal rated voltage | V | 690 | |
Utilization category | aR (accompanied semiconductor protection) | ||
Type of fuse status indicator | Top fuse status indicator | ||
Approvals
| Product Standards | UL 248-13 CE marking | ||
| UL File No. | E180276 | ||
| UL Category Control No. | JFHR2 | ||
| CSA File No. | UL report applies to both US and Canada | ||
| CSA Class No. | JFHR8 | ||
| North America Certification | UL recognized, certified by UL for use in Canada | ||
| Specially designed for North America | No | ||
| Max. Voltage Rating | 660V |
| Feature Name | Feature Value |
|---|---|
| Fuse construction type according to IEC 60269 (EF015865) | NH1 |
| Utilization category according to IEC 60269 (EF002572) | aR (accompanied semiconductor protection) |
| Insulated metal gripping lugs (IMGL) (EF012538) | No |
