EATON - MOELLER NH4 SINGLE POLE 1600A NH4 SINGLE POLE 1600A SD4-S1600 EATON ELECTRIC Fuse-base, LV, 1600 A, AC 690 V, NH4, 1P, IEC, screw mount View larger
Images are for illustrative purposes only. Please refer to data sheet for details

NH4 SINGLE POLE 1600A SD4-S1600 EATON ELECTRIC Fuse-base, LV, 1600 A, AC 690 V, NH4, 1P, IEC, screw mount

NH4 SINGLE POLE 1600A

SD4-S1600

SD4-S1600

EATON - MOELLER

1 Pcs.

Fuse-base, LV, 1600 A, AC 690 V, NH4, 1P, IEC, screw mount NH4 SINGLE POLE 1600A Eaton Bussmann series low voltage NH IP protection kit, Fuse Holder,NH4, SINGLE POLE, 1600A, Fuse Type NH

Automation > Low Voltage HRC fuse base
Bussmann Series Low Voltage fuses and accessories

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Engineered for extreme industrial power distribution, the NH4 SINGLE POLE 1600A from Eaton Moeller is a low voltage fuse-base designed to handle very high current ratings. These heavy-duty bases provide secure physical anchoring and low-resistance electrical connections for massive high-capacity fuse links in major industrial plants. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Manufacturer: Eaton Moeller
  • Manufacturer part number: NH4 SINGLE POLE 1600A
  • Catalogue code: SD4-S1600
  • Catalogue title: NH4 SINGLE POLE 1600A SD4-S1600 EATON ELECTRIC Fuse-base, LV, 1600 A, AC 690 V, NH4, 1P, IEC, screw mount
  • Product description: General specifications Product Name Eaton Bussmann series low voltage NH IP protection kit Catalog Number SD4-S1600 Model Code NH4 SINGLE POLE 1600A UPC 051712371568 Product Length/Depth 295 mm Product Height 122 mm Prod
  • Manufacturer summary: Fuse-base, LV, 1600 A, AC 690 V, NH4, 1P, IEC, screw mount NH4 SINGLE POLE 1600A Eaton Bussmann series low voltage NH IP protection kit, Fuse Holder,NH4, SINGLE POLE, 1600A, Fuse Type NH

More info

▲

General specifications

Product Name
Eaton Bussmann series low voltage NH IP protection kit
Catalog Number
SD4-S1600
Model Code
NH4 SINGLE POLE 1600A
UPC
051712371568
Product Length/Depth
295 mm
Product Height
122 mm
Product Width
90 mm
Product Weight
2451 g
Certifications
CE

Electrical rating

Amperage Rating
1600 A

Product specifications

Number of Poles
Single-pole

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
