View larger
Images are for illustrative purposes only. Please refer to data sheet for details
NZM2-XDV-MODAN 285764 Y7-285764 EATON ELECTRIC Rotary drive, Modan door coupling, rotary handle, size 2
NZM2-XDV-MODAN
285764
Y7-285764
EATON - MOELLER
1 Pcs.
Rotary drive, Modan door coupling, rotary handle, size 2
NZM2-XDV-MODAN
Optional accessories for circuit-breaker series NZM offers a comprehensive portfolio of application possibilities for worldwide use. Modular functional groups make mounting flexible and simple.
Automation > Handle for power circuit breaker
Circuit Breakers NZM
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲Rotary drive, Modan door coupling, rotary handle, size 2
Optional accessories for circuit-breaker series NZM offers a comprehensive portfolio of application possibilities for worldwide use. Modular functional groups make mounting flexible and simple.
Delivery program
Product range
Accessories
Accessories
Rotary handle on circuit-breaker
Standard/Approval
UL/CSA, IEC
Construction size
NZM2
Description
Makes it possible to operate the switch with a rotational movement and provides locking facilities
Function
Standard, black/grey
Protection class
IP20
Locking facility
Prepared for interlocking with MODAN drawer
Actuation
Rotary handle
For use with
NZM2(-4), PN2(-4), N(S)2(-4)
Notes
Circuit‐breaker can also be installed in a lying position 90 ° left/right, with the handle still in the same position.
Technical data ETIM 4.0
Lockable
No
Colour
Grey
Suitable for emergency stop
No
With axe
No
Suitable for power circuit breaker
Yes
Suitable for switch disconnector
Yes
| Feature Name | Feature Value |
|---|---|
| With restart blockage (EF004054) | No |
| With key lock (EF026057) | No |
| Padlock locking (EF001163) | No |
| Suitable for emergency stop (EF001433) | No |
| With extension shaft (EF001434) | No |
| Suitable for power circuit breaker (EF005863) | No |
| Suitable for switch disconnector (EF007252) | No |
