PV-DIS-06-125/2 179258 Y7-179258 EATON ELECTRIC Switch disconnector, DC, 600V, 125 A
PV-DIS-06-125/2
179258
Y7-179258
EATON - MOELLER
1 Pcs.
Connectors > Switch disconnector
Modular Switchgear – Industrial
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
PV-DIS-06-125/2 179258 Y7-179258 EATON ELECTRIC Switch disconnector, DC, 600V, 125 A provides essential load-breaking capabilities for photovoltaic and other high-voltage direct current applications. Technicians rely on these specialized switches to isolate DC lines safely during servicing or system overhauls. Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Version as main switch (EF006981): No
- Version as maintenance-/service switch (EF006986): Yes
- Version as safety switch (EF006985): No
- Version as emergency stop installation (EF006959): No
- Version as reversing switch (EF009408): No
- Number of switches (EF005586): 1
- Max. rated operation voltage Ue AC (EF007355): 0 V
- Rated operating voltage (EF001435): 600 V
- Rated permanent current Iu (EF001389): 0 A
- Rated permanent current at AC-23, 400 V (EF011777): 0 A
- Rated permanent current at AC-21, 400 V (EF009165): 0 A
- Rated operation power at AC-3, 400 V (EF001364): 0 kW
- Rated short-time withstand current lcw (EF007050): 1500 kA
- Rated operation power at AC-23, 400 V (EF007027): 0 kW
- Switching power at 400 V (EF009166): 0 kW
- Conditioned rated short-circuit current Iq (EF001444): 0 kA
More info
▲General specifications
RoHS conform
Product specifications
- Open areas
- Residential buildings
- Utility buildings
DC-PV1 (EN 60947-3)
IP20
IP40 (when fitted)
