EATON - MOELLER SW-XSOFT-CODESYS-2-S SW-XSOFT-CODESYS-2-S 142582 Y7-142582 EATON ELECTRIC Programming software, PLC(S), according to IEC61131-1, .. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

SW-XSOFT-CODESYS-2-S 142582 Y7-142582 EATON ELECTRIC Programming software, PLC(S), according to IEC61131-1, ..

SW-XSOFT-CODESYS-2-S

142582

Y7-142582

EATON - MOELLER

1 Pcs.

Programming software, PLC(S), according to IEC61131-1, single-user license SW-XSOFT-CODESYS-2-S All controllers of Eaton are programmed with XSoft-CoDeSys. The Software is based on standard CoDeSys of the company 3N/O. Technically sophisticated features, simple handling and the widely used software in automation components from different manufacturers are a guarantee for success. Programming languages: IL (AWL), structured Text (ST), function Block Diagram (FBD), freely graphical function block diagram (CFC), ladder Diagram (LD), sequential Function Chart (SFC)

Automation > Programming- and engineering software
HMI Touch Terminals

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Eaton Moeller SW-XSOFT-CODESYS-2-S is PLC programming software designed for developing industrial control logic in automation environments. This type of engineering software allows developers to write, configure, and test controller code using standardized programming languages to coordinate machinery and processes.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • With editor for programming language Flowchart (EF006647): Yes
  • Suitable for operating system Windows 9x (EF003041): No
  • Suitable for operating system Windows NT (EF003042): Yes
  • Suitable for operating system Windows 2000 (EF003043): No
  • Suitable for operating system Windows XP (EF003044): Yes
  • Suitable for operating system Windows ME (EF003045): No
  • Suitable for operating system Windows CE (EF003046): No
  • Suitable for operating system Linux (EF003047): No
  • Suitable for operating system Windows Vista (EF007091): Yes
  • Suitable for operating system Windows 2003 Server (EF007090): No
  • Suitable for operating system Windows 7 (EF008526): Yes
  • Suitable for operating system Windows 8 (EF009923): Yes
  • Suitable for other operating system (EF003048): Yes
  • Object library (EF003049): Integrated
  • Integrated diagnosis function (EF003063): Yes
  • Integrated configuration function (EF003064): Yes

More info

▲

General specifications

Product Name
Eaton CODESYS Software
Catalog Number
142582
Model Code
SW-XSOFT-CODESYS-2-S
EAN
7640130096844
Product Length/Depth
230 mm
Product Height
2 mm
Product Width
162 mm
Product Weight
0.016 kg

Product specifications

Fitted with:
Editor for programming language LD (Ladder Diagram)
Editor for programming language SFC (Sequential Function Chart)
Technology function integrated
Editor for programming language FBD (Function Block Diagram)
Editor for programming language IL (Instruction List)
Editor for programming language Flowchart
Editor for programming language ST (Structured Text)
Object library
Integrated
SIL (IEC 61508)
None
Functions
Data detection function
Communication function
Analysis function
Maintenance function integrated
Put into operation function integrated
Configuration function
Evaluation function
Simulation function integrated
Application configuration function
Motion function
Diagnosis function
Software
Menu selection in 5 languages
Operating systems: WIN NT 4.0 SP6, WIN 2000 SP3, WIN XP SP2, WINDOWS Vista, WINDOWS 7, WINDOWS 8
Comprehensive help and documentation
Supports XV, XC, XN, EC4P
Single-user license
OPC configurator
XSOFT-CODESYS-2
Programming to IEC 61131-1 with IL, ST, LAD, FBS, AS, CFC
Suitable for
Operating system Windows 8
Operating system Windows NT
Operating system Windows 7
Other operating system
Operating system Windows XP
Operating system Windows Vista

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
