EATON - MOELLER PLS6-D63/2 PLS6-D63/2 113405 Y7-113405 EATON ELECTRIC Miniature circuit breaker (MCB), 63A, 2 p, type D characteristic View larger
Images are for illustrative purposes only. Please refer to data sheet for details

PLS6-D63/2 113405 Y7-113405 EATON ELECTRIC Miniature circuit breaker (MCB), 63A, 2 p, type D characteristic

PLS6-D63/2

113405

Y7-113405

EATON - MOELLER

1 Pcs.

Miniature circuit breaker (MCB), 63A, 2 p, type D characteristic PLS6-D63/2 Eaton Moeller series xPole - PLS6/M MCB. PLS6, 2-poles, tripping characteristic: D, rated current In: 63 A Miniature circuit breaker (MCB), PLS6, 2-poles, tripping characteristic: D, rated current In: 63 A, Switchgear for residential and commercial applications

Automation > Miniature circuit breaker (MCB)
Modular Switchgear – Industrial

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

The Eaton Moeller PLS6-D63/2 miniature circuit breaker is designed to safeguard electrical distribution circuits by interrupting current flow during overloads and short-circuit faults. Such components protect wiring infrastructure and connected industrial loads from potential damage.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Built-in depth (EF000218): 70.5 mm
  • Release characteristic (EF000889): C
  • Number of poles (total) (EF008618): 2
  • Number of protected poles (EF005548): 2
  • Rated current (EF000227): 6 A
  • Rated voltage (EF000228): 230 V
  • Rated insulation voltage Ui (EF001366): 440 V
  • Rated impulse withstand voltage Uimp (EF011980): 4 kV
  • Voltage type (EF000187): AC
  • Frequency (EF000416): 50 Hz
  • Power loss (EF005387): 11.1 W
  • Current limiting class (EF002568): 3
  • Flush-mounted installation (EF007517): No
  • Concurrently switching neutral conductor (EF005997): No
  • Over voltage category (EF002569): 3
  • Pollution degree (EF002570): 2

More info

▲

General specifications

Product Name
Eaton Moeller series xPole - PLS6/M MCB
Catalog Number
113405
Model Code
PLS6-D63/2
EAN
4015081129508
Product Length/Depth
85 mm
Product Height
73 mm
Product Width
35 mm
Product Weight
0.24 kg
Compliances
RoHS conform

Delivery program

Number of poles (total)
2
Number of poles (protected)
2
Release characteristic
C
Amperage Rating
6 A

Technical data - electrical

Voltage type
AC
Rated operational voltage (Ue) - max
230 V
Rated insulation voltage (Ui)
440 V
Rated impulse withstand voltage (Uimp)
4 kV
Frequency rating - min
50 Hz
Frequency rating - max
60 Hz
Rated short-circuit breaking capacity (EN 60898) at 230 V
6 kA
Rated short-circuit breaking capacity (EN 60898) at 400 V
6 kA
Rated short-circuit breaking capacity (IEC 60947-2) at 230 V
0 kA
Rated short-circuit breaking capacity (IEC 60947-2) at 400 V
0 kA
Overvoltage category
III
Pollution degree
2

Technical data - mechanical

Width in number of modular spacings
2
Built-in depth
70.5 mm
Degree of protection
IP20
Connectable conductor cross section (solid-core) - min
1 mm²
Connectable conductor cross section (solid-core) - max
25 mm²
Connectable conductor cross section (multi-wired) - min
1 mm²
Connectable conductor cross section (multi-wired) - max
25 mm²

Design verification as per IEC/EN 61439 - technical data

Rated operational current for specified heat dissipation (In)
63 A
Heat dissipation per pole, current-dependent
0 W
Equipment heat dissipation, current-dependent
1.5 W
Static heat dissipation, non-current-dependent
0 W
Heat dissipation capacity
0 W
Ambient operating temperature - min
-25 °C
Ambient operating temperature - max
75 °C

Additional information

Current limiting class
3
Features
Additional equipment possible
Special features
Ambient temperature hint: a 1 °C increase results in a 0.5% linear reduction of current carrying capacity
