EATON - MOELLER P3-30/EA/SVB-MCS P3-30/EA/SVB-MCS 237892 Y7-237892 EATON ELECTRIC Pressure pipe flange, R1/4 View larger
Images are for illustrative purposes only. Please refer to data sheet for details

P3-30/EA/SVB-MCS 237892 Y7-237892 EATON ELECTRIC Pressure pipe flange, R1/4

P3-30/EA/SVB-MCS

237892

Y7-237892

EATON - MOELLER

1 Pcs.

Pressure pipe flange, R1/4 P3-30/EA/SVB-MCS Eaton Moeller® series P3 Main switch, P3, 30 A, flush mounting, 3 pole, With red rotary handle and yellow locking ring, Lockable in the 0 (Off) position, UL/CSA Main switch, Product range: Main switch, maintenance switch, Part group reference: P3, With red rotary handle and yellow locking ring, 3 pole, Locking facility: Lockable in the 0 (Off) position, Degree of Protection: Front IP65, Design: flush mounting, Rated uninterrupted current: Iu = 30 A, Standards: UL489

Connectors > Switch disconnector
Disconnectors and Cam Switches

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

A pressure pipe flange functions as a secure connecting element in industrial fluid and gas transport networks, providing a robust interface for joining pipes, valves, and system components. It is commonly deployed in commercial and industrial hydraulic or pneumatic circuits where dependable pressure retention and leak-free joints are required.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Version as main switch (EF006981): Yes
  • Version as maintenance-/service switch (EF006986): Yes
  • Version as safety switch (EF006985): No
  • Version as emergency stop installation (EF006959): Yes
  • Version as reversing switch (EF009408): No
  • Number of switches (EF005586): 1
  • Max. rated operation voltage Ue AC (EF007355): 480 V
  • Rated operating voltage (EF001435): 690 V
  • Rated permanent current Iu (EF001389): 30 A
  • Rated permanent current at AC-21, 400 V (EF009165): 0 A
  • Rated operation power at AC-3, 400 V (EF001364): 0 kW
  • Rated short-time withstand current lcw (EF007050): 0 kA
  • Rated operation power at AC-23, 400 V (EF007027): 0 kW
  • Switching power at 400 V (EF009166): 0 kW
  • Conditioned rated short-circuit current Iq (EF001444): 100 kA
  • Number of poles (EF001391): 3

More info

▲

General specifications

Product Name
Eaton Moeller® series P3 Main switch
Catalog Number
237892
Model Code
P3-30/EA/SVB-MCS
EAN
4015082378929
Product Length/Depth
150 mm
Product Height
114 mm
Product Width
90 mm
Product Weight
0.374 kg
Certifications
UL
CSA
UL File No.: E148671
UL489
CSA File No.: 1342868 (LR12528)
UL 489
