EATON - MOELLER P3-100/ST/SVB P3-100/ST/SVB 025520 EATON ELECTRIC Main switch, +steel enclosure, 3p, 100A, handle red yellow, lockable View larger
Images are for illustrative purposes only. Please refer to data sheet for details

P3-100/ST/SVB 025520 EATON ELECTRIC Main switch, +steel enclosure, 3p, 100A, handle red yellow, lockable

P3-100/ST/SVB

025520

EATON - MOELLER

1 Pcs.

Main switch, +steel enclosure, 3p, 100A, handle red yellow, lockable General switch; 3-pole; 100a; Mounting stainless steel box; Handle Red/Yellow Lockable on the 0 position (OFF) Main switch/switch-disconnector on-off according to IEC/EN 60947-3, 690V/100A, steel sheet enclosure, degree of protection Front IP55, handle red with yellow locking collar lockable with 3 padlocks, switch-disconnectors P3 have a very compact and robust design. The manual drive act directly to the connection of the contacts. The contacts are forced open when switching off. Design general: insulating material-surface mounting enclosure, flush mounting, rear mounting, IVS service distribution board mounting

Connectors > Switch disconnector
Disconnectors and Cam Switches

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Enclosed main switches serve as the primary point of isolation for industrial machinery, allowing operators to completely cut off electrical power directly at the machine housing. Housed in durable enclosures, they protect internal contacts from dust and moisture in harsh operating environments.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Version as main switch (EF006981): No
  • Version as maintenance-/service switch (EF006986): No
  • Version as safety switch (EF006985): No
  • Version as emergency stop installation (EF006959): No
  • Version as reversing switch (EF009408): No
  • Motor drive optional (EF007386): No
  • Motor drive integrated (EF006697): No
  • Voltage release optional (EF007491): No
  • Suitable for front mounting 4-hole (EF007247): No
  • Suitable for front mounting centre (EF007248): No
  • Suitable for distribution board installation (EF007262): No
  • Suitable for intermediate mounting (EF007264): No
  • Interlockable (EF006281): No
  • With pre-assembled cabling (EF016444): No
  • Width (EF000008): 185 mm
  • Height (EF000040): 185 mm

More info

▲
Main switch, +steel enclosure, 3p, 100A, handle red yellow, lockable
Main switch/switch-disconnector on-off according to IEC/EN 60947-3, 690V/100A, steel sheet enclosure, degree of protection Front IP55, handle red with yellow locking collar lockable with 3 padlocks, switch-disconnectors P3 have a very compact and robust design. The manual drive act directly to the connection of the contacts. The contacts are forced open when switching off. Design general: insulating material-surface mounting enclosure, flush mounting, rear mounting, IVS service distribution board mounting
[

Dimensions

]

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
