EATON - MOELLER P1-32/I2H P1-32/I2H 227866 Y7-227866 EATON ELECTRIC On-Off switch, 3 pole, 32 A, surface mounting, hard knockout versi.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

P1-32/I2H 227866 Y7-227866 EATON ELECTRIC On-Off switch, 3 pole, 32 A, surface mounting, hard knockout versi..

P1-32/I2H

227866

Y7-227866

EATON - MOELLER

1 Pcs.

On-Off switch, 3 pole, 32 A, surface mounting, hard knockout version P1-32/I2H Eaton Moeller® series P1 On-Off switch, P1, 32 A, surface mounting, 3 pole, with black thumb grip and front plate, hard knockout version On-Off switch, P1, Rated uninterrupted current (Iu): 32 A, Fitted with: Black thumb grip and front plate, Mounting method: Surface mounting, Number of poles: Three-pole, Degree of Protection: NEMA 12

Connectors > Switch disconnector
Disconnectors and Cam Switches

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Providing dependable manual control for industrial machinery, the Eaton Moeller P1-32/I2H acts as an on-off switch to govern power distribution across local circuits. Surface-mounted disconnect units are standard in factory automation setups to ensure operators can quickly interrupt power at the machine level.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Version as main switch (EF006981): No
  • Version as maintenance-/service switch (EF006986): No
  • Version as safety switch (EF006985): No
  • Version as emergency stop installation (EF006959): No
  • Version as reversing switch (EF009408): No
  • Number of switches (EF005586): 1
  • Max. rated operation voltage Ue AC (EF007355): 690 V
  • Rated operating voltage (EF001435): 690 V
  • Rated permanent current Iu (EF001389): 32 A
  • Rated permanent current at AC-23, 400 V (EF011777): 32 A
  • Rated permanent current at AC-21, 400 V (EF009165): 32 A
  • Rated operation power at AC-3, 400 V (EF001364): 13 kW
  • Rated short-time withstand current lcw (EF007050): 0.64 kA
  • Rated operation power at AC-23, 400 V (EF007027): 15 kW
  • Switching power at 400 V (EF009166): 15 kW
  • Conditioned rated short-circuit current Iq (EF001444): 80 kA

More info

▲

General specifications

Product Name
Eaton Moeller® series P1 On-off switch
Catalog Number
227866
Model Code
P1-32/I2H
EAN
4015082278663
Product Length/Depth
107 mm
Product Height
180 mm
Product Width
100 mm
Product Weight
0.422 kg
Certifications
IEC/EN 60947-3
CE
IEC/EN 60947
UL Category Control No.: NLRV
CSA File No.: 012528
CSA
CSA Class No.: 3211-05
CSA-C22.2 No. 94
UL
UL 60947-4-1
CSA-C22.2 No. 60947-4-1-14
IEC/EN 60204
UL File No.: E36332
VDE 0660
