PLZM-C6/1N-MW 242330 Y7-242330 EATON ELECTRIC Over current switch, 6A, 1pole+N, type C characteristic
PLZM-C6/1N-MW
242330
Y7-242330
EATON - MOELLER
1 Pcs.
Automation > Miniature circuit breaker (MCB)
Modular Switchgear – Industrial
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
A PLZM-C6/1N-MW Eaton Moeller overcurrent switch delivers reliable circuit protection by interrupting electrical flow when overloads or short circuits occur in building or industrial installations. These modular switching devices help protect branch circuits and maintain overall electrical safety.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Built-in depth (EF000218): 70.5 mm
- Release characteristic (EF000889): C
- Number of poles (total) (EF008618): 2
- Number of protected poles (EF005548): 1
- Rated current (EF000227): 6 A
- Rated voltage (EF000228): 230 V
- Rated insulation voltage Ui (EF001366): 440 V
- Rated impulse withstand voltage Uimp (EF011980): 4 kV
- Voltage type (EF000187): AC
- Frequency (EF000416): 50 Hz
- Current limiting class (EF002568): 3
- Flush-mounted installation (EF007517): No
- Concurrently switching neutral conductor (EF005997): Yes
- Over voltage category (EF002569): 3
- Pollution degree (EF002570): 2
- Additional equipment possible (EF008148): Yes
More info
▲General specifications
Product specifications
- Switchgear for residential and commercial applications
- xPole - Switchgear for residential and commercial applications
Concurrently switching N-neutral
PLZM
