FAZ-B6/1-DC 176066 Y7-176066 EATON ELECTRIC Miniature circuit breaker (MCB), 6A, 1p, type B characteristic, ..
FAZ-B6/1-DC
176066
Y7-176066
EATON - MOELLER
1 Pcs.
Automation > Miniature circuit breaker (MCB)
Modular Switchgear – Industrial
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
Protect direct current electrical systems from overloads and short circuits with this FAZ-B6/1-DC 176066 Y7-176066 EATON ELECTRIC Miniature circuit breaker (MCB), 6A, 1p, type B characteristic. DC miniature circuit breakers are critical components in renewable energy and control panel setups for safely interrupting fault currents.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Built-in depth (EF000218): 70.5 mm
- Release characteristic (EF000889): B
- Number of poles (total) (EF008618): 1
- Number of protected poles (EF005548): 1
- Rated current (EF000227): 6 A
- Rated voltage (EF000228): 250 V
- Rated insulation voltage Ui (EF001366): 440 V
- Rated impulse withstand voltage Uimp (EF011980): 4 kV
- Voltage type (EF000187): DC
- Frequency (EF000416): 50 Hz
- Power loss (EF005387): 1.2 W
- Current limiting class (EF002568): 3
- Flush-mounted installation (EF007517): No
- Concurrently switching neutral conductor (EF005997): No
- Over voltage category (EF002569): 3
- Pollution degree (EF002570): 2
