FAZ-D40/3-NA 102276 Y7-102276 EATON ELECTRIC Over current switch, 40A, 3p, D-Char, AC
FAZ-D40/3-NA
102276
Y7-102276
EATON - MOELLER
1 Pcs.
Automation > Miniature circuit breaker (MCB)
Modular Switchgear – Industrial
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
The FAZ-D40/3-NA 102276 Y7-102276 EATON ELECTRIC Over current switch, 40A, 3p, D-Char, AC is a robust three-phase circuit breaker designed to protect industrial machinery and motor supply lines against electrical overloads. Overcurrent switches disconnect faulty circuits safely to maintain operational safety.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Built-in depth (EF000218): 70.5 mm
- Release characteristic (EF000889): D
- Number of poles (total) (EF008618): 3
- Number of protected poles (EF005548): 3
- Rated current (EF000227): 40 A
- Rated voltage (EF000228): 415 V
- Rated insulation voltage Ui (EF001366): 440 V
- Rated impulse withstand voltage Uimp (EF011980): 4 kV
- Voltage type (EF000187): AC
- Frequency (EF000416): 50 Hz
- Power loss (EF005387): 9.3 W
- Current limiting class (EF002568): 3
- Flush-mounted installation (EF007517): No
- Concurrently switching neutral conductor (EF005997): No
- Over voltage category (EF002569): 3
- Pollution degree (EF002570): 2
More info
▲General specifications
UL (File No. E235139)
Specially designed for North America, suitable as BCPD
North America (UL listed, CSA certified)
IEC 60947-2
UL (Category Control Number DIVQ)
UL 489, CSA C22.2 No. 5
CSA (File No. 204453)
CE marking
CSA (Class No. 1432-01)
IEC/EN 60947-2
CSA-C22.2 No. 5-09
EN45545-2
IEC 61373
Product specifications
- Feeder circuits, branch circuits
- Switchgear for export to North America (UL-listed)
FAZ-NA
IP20 (IEC)
UL/CSA Type: -
IP20
Max. 2.4 Nm
UL: 2.8 Nm (25 lb-in) for AWG 10 - AWG 8
UL: 2.4 Nm (21 lb-in) for AWG 18 - AWG 12
