FAZ-C35/3-NA 102255 Y7-102255 EATON ELECTRIC Miniature circuit breaker (MCB), 35A, 3p, C-Char, AC
FAZ-C35/3-NA
102255
Y7-102255
EATON - MOELLER
1 Pcs.
Automation > Miniature circuit breaker (MCB)
Modular Switchgear – Industrial
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
Three-phase distribution lines require robust overcurrent protection devices like the FAZ-C35/3-NA 102255 Y7-102255 EATON ELECTRIC Miniature circuit breaker (MCB), 35A, 3p, C-Char, AC. These thermal-magnetic breakers trip reliably during overloads, isolating faulty circuits before permanent damage can occur to machinery. Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Built-in depth (EF000218): 70.5 mm
- Release characteristic (EF000889): C
- Number of poles (total) (EF008618): 3
- Number of protected poles (EF005548): 3
- Rated current (EF000227): 35 A
- Rated voltage (EF000228): 415 V
- Rated insulation voltage Ui (EF001366): 440 V
- Rated impulse withstand voltage Uimp (EF011980): 4 kV
- Voltage type (EF000187): AC
- Frequency (EF000416): 50 Hz
- Power loss (EF005387): 4.8 W
- Current limiting class (EF002568): 3
- Flush-mounted installation (EF007517): false
- Concurrently switching neutral conductor (EF005997): false
- Over voltage category (EF002569): 3
- Pollution degree (EF002570): 2
More info
▲General specifications
CSA-C22.2 No. 5-09
UL (Category Control Number DIVQ)
CE marking
IEC/EN 60947-2
CSA (File No. 204453)
UL 489, CSA C22.2 No. 5
IEC 60947-2
UL (File No. E235139)
Specially designed for North America, suitable as BCPD
UL 489
CSA (Class No. 1432-01)
EN45545-2
IEC 61373
Delivery program
- FAZ-NA
- Miniature circuit breaker
Technical data - electrical
Technical data - mechanical
IP20
IP40 (when fitted)
IP20 (IEC)
UL: 2.8 Nm (25 lb-in) for AWG 10 - AWG 8
Max. 2.4 Nm
UL: 4 Nm (36 lb-in) for AWG 6
Design verification as per IEC/EN - technical data
Design verification as per IEC/EN 61439
Additional information
Miniature circuit breaker
