AZ-3N-B20 174519 Y7-174519 EATON ELECTRIC Miniature circuit breaker (MCB), 20A, 3pole+N, type B characterist..
AZ-3N-B20
174519
Y7-174519
EATON - MOELLER
1 Pcs.
Automation > Miniature circuit breaker (MCB)
Modular Switchgear – Industrial
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
Eaton Moeller part number AZ-3N-B20 is a AZ-3N-B20 174519 Y7-174519 EATON ELECTRIC Miniature circuit breaker (MCB), 20A, 3pole+N, type B characterist.. used in multi-phase electrical distribution systems to provide comprehensive overload and short-circuit protection. It safely interrupts fault currents across multiple lines simultaneously. Final pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Built-in depth: 75 mm
- Release characteristic: B
- Number of poles (total): 4
- Number of protected poles: 3
- Rated current: 20 A
- Rated voltage: 400 V
- Rated insulation voltage Ui: 440 V
- Rated impulse withstand voltage Uimp: 4 kV
- Voltage type: AC
- Frequency: 50 Hz
- Current limiting class: 3
- Flush-mounted installation: No
- Concurrently switching neutral conductor: Yes
- Over voltage category: 3
- Pollution degree: 2
- Additional equipment possible: Yes
More info
▲General specifications
IEC 61373
Delivery programme
- AZ
- Miniature circuit breaker
Technical data - electrical
Technical data - mechanical
Design verification as per IEC/EN 61439 - technical data
Design verification as per IEC/EN 61439
Additional information
Concurrently switching N-neutral
AZ
