FAZ-B20/2-DC 176082 Y7-176082 EATON ELECTRIC Miniature circuit breaker (MCB), 20A, 2 p, type B characteristi..
FAZ-B20/2-DC
176082
Y7-176082
EATON - MOELLER
1 Pcs.
Automation > Miniature circuit breaker (MCB)
Modular Switchgear – Industrial
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
Engineered for direct current systems, the FAZ-B20/2-DC 176082 Y7-176082 EATON ELECTRIC Miniature circuit breaker (MCB), 20A, 2 p, type B characteristi.. ensures reliable circuit protection in specialized DC applications. DC-rated circuit breakers are widely deployed in photovoltaic installations, battery storage setups, and industrial control systems.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Built-in depth (EF000218): 70.5 mm
- Release characteristic (EF000889): B
- Number of poles (total) (EF008618): 2
- Number of protected poles (EF005548): 2
- Rated current (EF000227): 20 A
- Rated voltage (EF000228): 500 V
- Rated insulation voltage Ui (EF001366): 440 V
- Rated impulse withstand voltage Uimp (EF011980): 4 kV
- Voltage type (EF000187): DC
- Frequency (EF000416): 50 Hz
- Power loss (EF005387): 5.8 W
- Current limiting class (EF002568): 3
- Flush-mounted installation (EF007517): No
- Concurrently switching neutral conductor (EF005997): No
- Over voltage category (EF002569): 3
- Pollution degree (EF002570): 2
