NZMS2-4-AX25 193370 EATON ELECTRIC Automatic Int. NZM2 PXR10, 25A, 4p, Screw Terminal
NZMS2-4-AX25
193370
EATON - MOELLER
1 Pcs.
Automation > Power circuit-breaker for trafo/generator/installation protection
Circuit Breakers NZM
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
This Eaton Moeller NZMS2-4-AX25 circuit breaker delivers reliable overload and short-circuit protection for commercial and industrial electrical applications. Multi-pole protective devices of this kind are commonly deployed in control panels to guard electrical circuits against excessive current spikes and operational faults. Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Vertical and 90° in all directions: With XFI earth-fault release:
- Rated voltage (EF003977): 690 V
- Overload release current setting (EF002336): 20 A
- Adjustment range undelayed short-circuit release (EF007131): 2 A
- Device construction (EF008240): Built-in device fixed built-in technique
- Integrated earth fault protection (EF007296): No
- Type of electrical connection of main circuit (EF006819): Screw connection
- Suitable for DIN rail (top hat rail) mounting (EF007250): No
- DIN rail (top hat rail) mounting optional (EF008904): Yes
- With switched-off indicator (EF007006): No
- With integrated under voltage release (EF001390): No
- Number of poles (EF001391): 4
- Position of connection for main current circuit (EF006671): Front
- Type of control element (EF006976): Rocker lever
- Complete device with protection unit (EF008906): Yes
- Motor drive integrated (EF006697): No
More info
▲Delivery program
R.m.s. value measurement and “thermal memory”
USB interface for configuration and test function with Power Xpert Protection Manager software
Technical data
Damp heat, cyclic, to IEC 60068-2-30
With door coupling rotary handle: IP66
Phase isolator and strip terminal: IP00
