EATON - MOELLER 32NHG000BI-690 32NHG000BI-690 EATON ELECTRIC Fuse-link, high speed, 125 A, AC 690 V, size 000, 24 x 36 x 96 mm, aR, IEC View larger
Images are for illustrative purposes only. Please refer to data sheet for details

32NHG000BI-690 EATON ELECTRIC Fuse-link, high speed, 125 A, AC 690 V, size 000, 24 x 36 x 96 mm, aR, IEC

32NHG000BI-690

32NHG000BI690

EATON - MOELLER

3 Pcs.

NH FUSE 32A 690V SIZE 000 GG IMGL Fuse-link, LV, 32 A, AC 690 V, NH000, gL/gG, IEC, dual indicator, insulated gripping lugs Fuse, Fuse-link, low voltage, 32 A, AC 690 V, NH000, gL/gG, IEC, dual (combination) indicator system, square-body with knife blade contacts, insulated gripping lugs, IEC 60269-2 fuse system A, DIN 43620, VDE 0636-2, Breaking Capacity 120 kA

Automation > Low Voltage HRC fuse
Bussmann Series Low Voltage fuses and accessories

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Fuse-link, high speed, 125 A, AC 690 V, size 000 part 32NHG000BI-690 by Eaton Electric offers rapid overcurrent protection for specialized electrical equipment. High-speed fuses are typically installed in industrial control panels and power electronics to safeguard against transient fault conditions.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Fuse construction type according to IEC 60269 (EF015865): NH000
  • Voltage type (EF000187): AC
  • Rated current (EF000227): 32 A
  • Rated voltage AC (EF007682): 690 V
  • Rated switching capacity AC (EF017698): 120 kA
  • Utilization category according to IEC 60269 (EF002572): gG (cable protection/equipment protection)
  • Type of fuse status indicator (EF004473): Combination fuse status indicator
  • Insulated metal gripping lugs (IMGL) (EF012538): Yes
  • Power loss at rated current (EF012389): 305 W

More info

▲

General specifications

Product Name
Eaton Bussmann series low voltage NH Fuse
Catalog Number
32NHG000BI-690
Model Code
NH FUSE 32A 690V SIZE 000 GG IMGL
EAN
5027590476867
Product Length/Depth
79 mm
Product Height
51 mm
Product Width
21 mm
Product Weight
131 g
Compliances
RoHS Compliant
CE Marked
Certifications
IEC 60269-1
IEC 60269-2
DIN 43620

Electrical data

Amperage Rating
32 A
Voltage rating
690 V
Voltage type
AC
Breaking capacity
120 kA
Class
Class gG/gL

Product specification

Fuse size
NH000
Insulated metal gripping lugs (IMGL)
Yes

Accessories

Suitable for
Microswitch 170H0236
EBF Vertical fuse rail
EBV Vertical fuse switch-disconnectors
EBH Size 000 Horizontal fuse switch-disconnectors

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
