View larger
Images are for illustrative purposes only. Please refer to data sheet for details
NH FUSE 125A 500V GL/GG SIZE 01 125NHG01BI EATON ELECTRIC Fuse-link, LV, 125 A, AC 500 V, NH01, gL/gG, IEC, ..
NH FUSE 125A 500V GL/GG SIZE 01
125NHG01BI
125NHG01BI
EATON - MOELLER
3 Pcs.
Fuse-link, LV, 125 A, AC 500 V, NH01, gL/gG, IEC, dual indicator, insulated gripping lugs
NH FUSE 125A 500V GL/GG SIZE 01
Eaton Bussmann series low voltage NH Fuse, 500V, 125A, 120 kAIC, Combination fuse status indicator, fuse, Class C gL/gG
Automation > Low Voltage HRC fuse
Bussmann Series Low Voltage fuses and accessories
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲General specifications
Product Name
Eaton Bussmann series low voltage NH Fuse
Catalog Number
125NHG01BI
EAN
5027590429993
UPC
051712232890
Product Length/Depth
135 mm
Product Height
58 mm
Product Width
30 mm
Product Weight
295 g
Compliances
RoHS Compliant
CE Marked
CE Marked
Certifications
IEC 60269-1
IEC 60269-2
DIN 43620
IEC 60269-2
DIN 43620
Electrical data
Amperage Rating
125 A
Voltage rating
500 V
Voltage type
AC
Breaking capacity
120 kA
Class
Class gG/gL
Frequency rating - min
45 Hz
Frequency rating - max
62 Hz
Product specification
Fuse size
NH3
Insulated metal gripping lugs (IMGL)
Yes
No
No
Accessories
Suitable for
SD3-D Single pole NH Fuse base
TD3-D Tripe pole NH Fuse base
Microswitch 170H0235
EBH Size 00 to 4 Horizontal fuse switch-disconnectors
TD3-D Tripe pole NH Fuse base
Microswitch 170H0235
EBH Size 00 to 4 Horizontal fuse switch-disconnectors
| Feature Name | Feature Value |
|---|---|
| Fuse construction type according to IEC 60269 (EF015865) | NH01 |
| Voltage type (EF000187) | AC |
| Rated current (EF000227) | 125 A |
| Rated voltage AC (EF007682) | 500 V |
| Utilization category according to IEC 60269 (EF002572) | gG (cable protection/equipment protection) |
| Type of fuse status indicator (EF004473) | Combination fuse status indicator |
| Insulated metal gripping lugs (IMGL) (EF012538) | Yes |
