PLZM-D6/1N-MW 242353 Y7-242353 EATON ELECTRIC Over current switch, 6A, 1pole+N, type D characteristic
PLZM-D6/1N-MW
242353
Y7-242353
EATON - MOELLER
1 Pcs.
Automation > Miniature circuit breaker (MCB)
Modular Switchgear – Industrial
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
An Eaton Moeller PLZM-D6/1N-MW over current switch is designed to provide reliable circuit protection against overloads and short circuits in residential and commercial electrical systems, featuring concurrent neutral switching. Such devices ensure automatic interruption of power when fault currents exceed safe parameters.
Pricing, availability, and lead time are confirmed per enquiry through an RFQ.
- Built-in depth (EF000218): 70.5 mm
- Release characteristic (EF000889): D
- Number of poles (total) (EF008618): 2
- Number of protected poles (EF005548): 1
- Rated current (EF000227): 6 A
- Rated voltage (EF000228): 230 V
- Rated insulation voltage Ui (EF001366): 440 V
- Rated impulse withstand voltage Uimp (EF011980): 4 kV
- Voltage type (EF000187): AC
- Frequency (EF000416): 50 Hz
- Current limiting class (EF002568): 3
- Flush-mounted installation (EF007517): No
- Concurrently switching neutral conductor (EF005997): Yes
- Over voltage category (EF002569): 3
- Pollution degree (EF002570): 2
- Additional equipment possible (EF008148): Yes
More info
▲General specifications
Product specifications
PLZM
- Switchgear for residential and commercial applications
- xPole - Switchgear for residential and commercial applications
Additional equipment possible
