EATON - MOELLER MFD-COMBINATION MFD-COMBINATION 2010801 EATON ELECTRIC MFD combination, customized inscription, customized type View larger
Images are for illustrative purposes only. Please refer to data sheet for details

MFD-COMBINATION 2010801 EATON ELECTRIC MFD combination, customized inscription, customized type

MFD-COMBINATION

2010801

EATON - MOELLER

1 Pcs.

MFD combination, customized inscription, customized type MFD combination; For custom appliances Custom labeling of multi-function display using the Label Editor inscription software, or multi-function display delivered programmed with user program

Automation > Accessories/spare parts for controls
EASY programmable relays and MFD displays

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲
MFD combination, customized inscription, customized type
Custom labeling of multi-function display using the Label Editor inscription software, or multi-function display delivered programmed with user program

Delivery program

Product range
Multi-function-display MFD-Titan
Accessories
Individual laser inscription
Description
Custom labeling of multi-function display with inscription software Labeleditor or supply of multi-function display programmed with user program
For use with
MFD80
MFD-CP8
MFD-CP10
Notes

Individually inscribe your device in 4 stages:

  • Download the inscription software: www.moeller.net/support, keyword: “Labeleditor”
  • Creation of label template (menu-guided in the software)
  • Send the label template to the factory by email. The email address is automatically set for the selected product by the program. When your template is sent, the Labeleditor issues a file name such as “EASY_12345.zip”. This file name is part of the article to be ordered (see Ordering examples).
  • Send order to the Eaton office or the electrical wholesalers.
Notes

Ordering example: MFD-Titan

MFD-80-B multi-function display with “company name”:

1 x MFD-COMBINATION-*

1 x MFD-80-B

1 x the file name “MFD_xxxxx.zip” issued by the Labeleditor

Design verification as per IEC/EN 61439

Operating ambient temperature min.
-25 °C
Operating ambient temperature max.
+55 °C

Technical data ETIM 7.0

PLC's (EG000024) / Accessories for controls (EC002584)
Electric engineering, automation, process control engineering / Control / Programmable logic control (SPS) / Programmable logic control (SPS, accessories) ([email protected] [AFR333003])
Type of electrical accessory
Other
Type of mechanical accessory
Other

Approvals

North America Certification
UL/CSA certification not required

ETIM for 2010801 PLC's (EC002584)
Feature Name Feature Value
Accessory (EF013236) No
Spare part (EF013237) No
