EATON - MOELLER 3.6KV 200AMP 2.5" OIL FUSE 3.6KV 200AMP 2.5" OIL FUSE 3.6OEFM27200 EATON ELECTRIC VT fuse-link, medium voltage, 3 A, AC 15.5 kV, 254 x .. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

3.6KV 200AMP 2.5" OIL FUSE 3.6OEFM27200 EATON ELECTRIC VT fuse-link, medium voltage, 3 A, AC 15.5 kV, 254 x ..

3.6KV 200AMP 2.5" OIL FUSE

3.6OEFM27200

EATON - MOELLER

2 Pcs.

VT fuse-link, medium voltage, 3 A, AC 15.5 kV, 254 x 25.4 mm, back-up, BS, IEC, style 22 tags, oil tight 3.6KV 200AMP 2.5" OIL FUSE 3.6KV 200AMP 2.5" OIL FUSE - Oil fuse-link, medium voltage, 200 A, AC 3.6 kV, 64 x 254 mm, back-up, BS, with striker Fuse, Oil fuse-link, medium voltage, 200 A, AC 3.6 kV, 64 x 254 mm, back-up, BS, with striker, cylindrical with radial bolted tag, protection of primary side transformers, BS2692-1, Breaking Capacity 50 kA

Automation > Medium-/high voltage fuse
Bussmann Series Medium Voltage fuses and accessories

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Designed by Eaton Moeller, the 3.6KV 200AMP 2.5" OIL FUSE acts as a VT fuse-link, medium voltage deployed in oil-filled switchgear to manage primary side transformer protection. Oil-immersed medium-voltage fuses safely clear electrical faults inside enclosed switchgear assemblies.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Rated current (EF000227): 200 A
  • Rated voltage (EF000228): 3.6 kV
  • Voltage type (EF000187): AC
  • Rated frequency (EF001663): 50 Hz
  • Breaking capacity (EF005617): 50 kA
  • Application (EF000041): Primary side transformer protection
  • Length (EF001438): 0.001 mm
  • Performance category according to IEC 60282-1 (EF012539): Back-up
  • With striker (EF008175): Yes
  • Standard (EF009322): British Standard
  • Installation technique (EF001474): Oil

More info

▲
Oil fuse-link, medium voltage, 200 A, AC 3.6 kV, 64 x 254 mm, back-up, BS, with striker
Fuse, Oil fuse-link, medium voltage, 200 A, AC 3.6 kV, 64 x 254 mm, back-up, BS, with striker, cylindrical with radial bolted tag, protection of primary side transformers, BS2692-1, Breaking Capacity 50 kA

Delivery program

Product range
Fuse
Basic function
Oil fuse-link
Field of application
medium voltage
Rated current [I]
200 A
Rated voltage
AC 3.6 kV
Size
64 x 254 mm
Utilization category
back-up
Status indicator
with striker
Breaking Capacity
50 kA
usable for size/applications
protection of primary side transformers
Standard/Approval
BS
Shape
cylindrical with radial bolted tag
Standards/Regulations
BS2692-1

Technical data ETIM 7.0

Circuit breakers and fuses (EG000020) / Medium-/high voltage fuse (EC003507)
Rated current
200 A
Rated voltage
3.6 kV
Voltage type
AC
Rated frequency
50 - 50 Hz
Breaking capacity
50 kA
Utilization category
Other
Application
Primary side transformer protection
Length
254 mm
Diameter
63.5 mm
Performance category according to IEC 60282-1
Back-up
With striker
Yes
Standard
British Standard
Release characteristic
Other
Installation technique
Oil

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
