EATON - MOELLER Medium Voltage - Motor Medium Voltage Motor 3.6ADGHC50 EATON ELECTRIC Motor fuse-link, medium voltage, 63 A, AC 3.6 kV, 51 x 254 mm.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

Medium Voltage Motor 3.6ADGHC50 EATON ELECTRIC Motor fuse-link, medium voltage, 63 A, AC 3.6 kV, 51 x 254 mm..

Medium Voltage - Motor

3.6ADGHC50

EATON - MOELLER

3 Pcs.

Motor fuse-link, medium voltage, 63 A, AC 3.6 kV, 51 x 254 mm, back-up, BS, with striker, no tags 3.6KV 50A 2" AIR FUSE 3.6KV 50Amp 2" 'C' Motorstart Fuse - Air fuse-link, medium voltage, 50 A, AC 3.6 kV, 51 x 461 mm, back-up, BS, with striker

Automation > Medium-/high voltage fuse
Bussmann Series Medium Voltage fuses and accessories

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Designed for specialized motor protection, this Eaton Moeller Medium Voltage - Motor component acts as a reliable interrupting device in heavy-duty industrial applications. Fuses of this classification interrupt fault currents quickly to prevent damage to expensive drive systems. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Manufacturer: Eaton Moeller
  • Manufacturer part number: Medium Voltage - Motor
  • Catalogue code: 3.6ADGHC50
  • Catalogue title: Medium Voltage Motor 3.6ADGHC50 EATON ELECTRIC Motor fuse-link, medium voltage, 63 A, AC 3.6 kV, 51 x 254 mm..
  • Product description: Air fuse-link, medium voltage, 50 A, AC 3.6 kV, 51 x 461 mm, back-up, BS, with striker Fuse, Air fuse-link, medium voltage, 50 A, AC 3.6 kV, 51 x 461 mm, back-up, BS, with striker, cylindrical with offset bolted tags, pr
  • Manufacturer summary: Motor fuse-link, medium voltage, 63 A, AC 3.6 kV, 51 x 254 mm, back-up, BS, with striker, no tags 3.6KV 50A 2" AIR FUSE 3.6KV 50Amp 2" 'C' Motorstart Fuse - Air fuse-link, medium voltage, 50 A, AC 3.6 kV, 51 x 461 mm, ba

More info

▲
Air fuse-link, medium voltage, 50 A, AC 3.6 kV, 51 x 461 mm, back-up, BS, with striker
Fuse, Air fuse-link, medium voltage, 50 A, AC 3.6 kV, 51 x 461 mm, back-up, BS, with striker, cylindrical with offset bolted tags, protection of primary side transformers, BS2692-1

Delivery program

Product range
Fuse
Basic function
Air fuse-link
Field of application
medium voltage
Rated current [I]
50 A
Rated voltage
AC 3.6 kV
Size
51 x 461 mm
Utilization category
back-up
Status indicator
with striker
usable for size/applications
protection of primary side transformers
Standard/Approval
BS
Shape
cylindrical with offset bolted tags
Standards/Regulations
BS2692-1

Technical data ETIM 7.0

Circuit breakers and fuses (EG000020) / Medium-/high voltage fuse (EC003507)
Rated current
50 A
Rated voltage
3.6 kV
Voltage type
AC
Rated frequency
50 - 50 Hz
Breaking capacity
25 kA
Utilization category
Other
Application
Primary side transformer protection
Length
461 mm
Diameter
51 mm
Performance category according to IEC 60282-1
Back-up
With striker
Yes
Standard
British Standard
Release characteristic
Other
Installation technique
Air
