View larger
Images are for illustrative purposes only. Please refer to data sheet for details
7.2KV 6.3Amp 2" DIN Sealed Fuse 7.2TDLSJ6.3 7-2TDLSJ6-3 EATON ELECTRIC 7.2KV 6.3AMP 2" DIN SEALED BROWN BODY
7.2KV 6.3Amp 2" DIN Sealed Fuse
7.2TDLSJ6.3
7-2TDLSJ6-3
EATON - MOELLER
3 Pcs.
7.2KV 6.3AMP 2" DIN SEALED BROWN BODY
7.2KV 6.3Amp 2"" DIN Sealed Fuse
7.2KV 6.3Amp 2" DIN Sealed Fuse - Fuse-link, medium voltage, 6.3 A, AC 7.2 kV, 40 kA, 2", 51 x 292 mm, back-up, DIN, with striker
Automation > Medium-/high voltage fuse
Bussmann Series Medium Voltage fuses and accessories
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲Fuse-link, medium voltage, 6.3 A, AC 7.2 kV, 40 kA, 2", 51 x 292 mm, back-up, DIN, with striker
Fuse, Fuse-link, medium voltage, 6.3 A, AC 7.2 kV, 2", 51 x 292 mm, Back-up, DIN, with striker, transformer protection, indoor or outdoor use, DIN 43625, VDE 0670 Part 4, VDE 0670 Part 402, IEC 60282-1, Breaking Capacity 40 kA
Delivery program
Product range
Fuse
Basic function
Fuse-link
Field of application
medium voltage
Rated current [I]
6.3 A
Rated voltage
AC 7.2 kV
Construction size
2"
Size
51 x 292 mm
Utilization category
back-up
Status indicator
with striker
Breaking Capacity
40 kA
usable for size/applications
transformer protection
indoor or outdoor use
indoor or outdoor use
Standard/Approval
DIN
Standards/Regulations
DIN 43625
VDE 0670-4
VDE 0670-402
IEC 60282-1
VDE 0670-4
VDE 0670-402
IEC 60282-1
Technical data ETIM 7.0
Circuit breakers and fuses (EG000020) / Medium-/high voltage fuse (EC003507)
Rated current
6.3 A
Rated voltage
7.2 kV
Voltage type
AC
Rated frequency
50 - 50 Hz
Breaking capacity
40 kA
Utilization category
Other
Application
Primary side transformer protection
Length
292 mm
Diameter
51 mm
Performance category according to IEC 60282-1
Back-up
With striker
Yes
Standard
DIN
Release characteristic
Other
Installation technique
Air
