EATON - MOELLER 5.5KV 3E RATED FUSE 5.5KV 3E RATED FUSE 5.5ABWNA3E 5-5ABWNA3E EATON ELECTRIC 2x Auxilliary compartment (cable area), HxW 700x400.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

5.5KV 3E RATED FUSE 5.5ABWNA3E 5-5ABWNA3E EATON ELECTRIC 2x Auxilliary compartment (cable area), HxW 700x400..

5.5KV 3E RATED FUSE

5.5ABWNA3E

5-5ABWNA3E

EATON - MOELLER

1 Pcs.

2x Auxilliary compartment (cable area), HxW=700x400mm 5.5KV 3E RATED FUSE 5.5KV 3E RATED FUSE - VT fuse-link, medium voltage, 3 A, AC 5.5 kV, 50 kA, 142 x 25.4 mm, back-up, BS, IEC, US, type E, 3E Fuse, VT fuse-link, medium voltage, 3 A, AC 5.5 kV, 142 x 25.4 mm, back-up, BS, IEC, US, 3E, cylindrical, type E, voltage and auxiliary transformers, BS2692-1, IEC 60282-1, ANSI C37-41, Breaking Capacity 50 kA

Automation > Medium-/high voltage fuse
Bussmann Series Medium Voltage fuses and accessories

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

An Eaton Moeller 5.5KV 3E RATED FUSE (5.5ABWNA3E) serves as an auxiliary transformer protection device tailored for medium-voltage electrical installations. Specialized E-rated fuses provide precise overcurrent clearing characteristics for transformer and potential circuits.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Rated current (EF000227): 3 A
  • Rated voltage (EF000228): 5.5 kV
  • Voltage type (EF000187): AC
  • Breaking capacity (EF005617): 50 kA
  • Application (EF000041): Auxiliary transformer protection
  • Length (EF001438): 142 mm
  • Diameter (EF000551): 25.4 mm
  • Performance category according to IEC 60282-1 (EF012539): Back-up
  • With striker (EF008175): No
  • Standard (EF009322): British Standard
  • Release characteristic (EF000889): E
  • Installation technique (EF001474): Air

More info

▲
VT fuse-link, medium voltage, 3 A, AC 5.5 kV, 50 kA, 142 x 25.4 mm, back-up, BS, IEC, US, type E, 3E
Fuse, VT fuse-link, medium voltage, 3 A, AC 5.5 kV, 142 x 25.4 mm, back-up, BS, IEC, US, 3E, cylindrical, type E, voltage and auxiliary transformers, BS2692-1, IEC 60282-1, ANSI C37-41, Breaking Capacity 50 kA

Delivery program

Product range
Fuse
Basic function
VT fuse-link
Field of application
medium voltage
Rated current [I]
3 A
Rated voltage
AC 5.5 kV
Size
142 x 25.4 mm
Utilization category
back-up
Description
type E
Breaking Capacity
50 kA
usable for size/applications
voltage and auxiliary transformers
Release characteristic [class]
3E
Standard/Approval
BS
IEC
US
Shape
cylindrical
Standards/Regulations
BS2692-1
IEC 60282-1
ANSI C37-41

Technical data ETIM 7.0

Circuit breakers and fuses (EG000020) / Medium-/high voltage fuse (EC003507)
Rated current
3 A
Rated voltage
5.5 kV
Voltage type
AC
Rated frequency
60 - 60 Hz
Breaking capacity
50 kA
Utilization category
Other
Application
Auxiliary transformer protection
Length
254 mm
Diameter
25.4 mm
Performance category according to IEC 60282-1
Back-up
With striker
No
Standard
British Standard
Release characteristic
E
Installation technique
Air
