> EATON - MOELLER > Bussmann Series Fuses holders and telecoms > CNEHS
EATON - MOELLER MAIN ASSEMBLY - 7893018 MAIN ASSEMBLY 7893018 CNE-HS EATON ELECTRIC Expansion anchor for ARC-SL assembly View larger
Images are for illustrative purposes only. Please refer to data sheet for details

MAIN ASSEMBLY 7893018 CNE-HS EATON ELECTRIC Expansion anchor for ARC-SL assembly

MAIN ASSEMBLY - 7893018

CNEHS

CNE-HS

EATON - MOELLER

10 Pcs.

Expansion anchor for ARC-SL assembly MAIN ASSEMBLY - 7893018 CNE-HS - Connector, low voltage, 100 A, AC 415 V, BS1361, 1P, BS, combined neutral and earth module Fuse holder accessory, Connector, low voltage, 100 A, AC 415 V, BS1361, 1P, BS, neutral and earth module, combined, for house-service cut-out, BS 7657, Breaking Capacity 33 kA, Optional accessories, Supplied with

Automation > Accessories/spare parts for electrical fuses/fuse holders
Bussmann Series Fuses holders and telecoms

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Serving a critical structural role, the Eaton Moeller MAIN ASSEMBLY - 7893018 expansion anchor secures structural elements and housings within specialized enclosure assemblies. Mechanical anchors provide high pull-out resistance to withstand environmental stresses and operational vibrations. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Accessory (EF013236): Yes
  • Spare part (EF013237): No

More info

▲
Connector, low voltage, 100 A, AC 415 V, BS1361, 1P, BS, combined neutral and earth module
Fuse holder accessory, Connector, low voltage, 100 A, AC 415 V, BS1361, 1P, BS, neutral and earth module, combined, for house-service cut-out, BS 7657, Breaking Capacity 33 kA

Delivery program

Product range
Fuse holder accessory
Basic function
Connector
Field of application
low voltage
Rated current [I]
100 A
Rated voltage
AC 415 V
Construction size
BS1361
Description
neutral and earth module, combined
Breaking Capacity
33 kA
Number of poles
1P
usable for size/applications
for house-service cut-out
Standard/Approval
BS
Standards/Regulations
BS 7657

Technical data ETIM 7.0

Circuit breakers and fuses (EG000020) / Accessories for electrical fuses/fuse holders (EC002936)
Type of accessory
Other
Suitable for
Other
Construction size fuse insert
Other

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
