M22-LED-W 216557 Y7-216557 EATON ELECTRIC LED element, white, front mount, 12-30VAC/DC
M22-LED-W
216557
Y7-216557
EATON - MOELLER
1 Pcs.
Automation > Lamp holder block for control circuit devices
Auxiliary Control and Signalling Elements
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
An Eaton Moeller M22-LED-W LED element is a front-mount signaling device used behind pushbuttons and control switches to deliver visual feedback in control panels. These elements are standard across industrial control circuits for indicating active processes and equipment status.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Transformer integrated (EF001358): No
- With integrated voltage decreasing resistor (EF001399): No
- With light source (EF005905): Yes
- With integrated diode (EF001400): Yes
- Rated voltage Ue at AC 50 Hz (EF007029): 12 V
- Rated voltage Ue at AC 60 Hz (EF007030): 12 V
- Rated voltage Ue at DC (EF007031): 12 V
- Voltage type for actuating (EF008242): AC/DC
- Lamp type (EF002423): LED
- Connection type auxiliary circuit (EF006820): Screw connection
- Colour light source (EF001402): White
- Type of fastening (EF002442): Front fastening
More info
▲General specifications
CSA File No.: 012528
IEC/EN 60947-5
UL 508
UL File No.: E29184
UL
UL Category Control No.: NKCR
CSA-C22.2 No. 14-05
CSA-C22.2 No. 94-91
IEC 60947-5-1
CE
CSA
Features & Functions
Light source
General
Ambient conditions, mechanical
Mechanical, According to IEC/EN 60068-2-27
Climatic environmental conditions
Damp heat, constant, to IEC 60068-2-78
