EATON - MOELLER IS-40/3 IS-40/3 276272 Y7-276272 EATON ELECTRIC Main switch, 240 V, 40A, 3HP View larger
Images are for illustrative purposes only. Please refer to data sheet for details

IS-40/3 276272 Y7-276272 EATON ELECTRIC Main switch, 240 V, 40A, 3HP

IS-40/3

276272

Y7-276272

EATON - MOELLER

1 Pcs.

Main switch, 240 V, 40A, 3HP IS-40/3 Main load disconnector Switch with isolation function, highly wear resistant contacts and classified for the use in rail rolling stock, 240/415 V, 40 A, 3P Switch with isolating function, type conform to IEC/EN 60947-3, contact with high wear resistance, jump activation, thumb-gripcolour black, terminal cross-section 50mm², busbar compatible with Xpole protection switching devices when using the jaw clamp in combination with standard fork busbars

Automation > Main switch for distribution board
Modular Switchgear – Others and Accessories

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

An Eaton Moeller IS-40/3 main switch provides reliable load breaking and circuit isolation capabilities in commercial and industrial electrical distribution setups. Devices of this type are routinely installed to manually disconnect sections of a power system during maintenance or emergency procedures. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Number of contacts as normally open contact (EF008256): 3
  • Number of contacts as normally closed contact (EF008255): 3
  • Number of contacts as change-over contact (EF008257): 0
  • Number of poles (EF001391): 3
  • Rated current (EF000227): 40 A
  • Rated voltage (EF000228): 415 V
  • Min. rated voltage (EF005025): 240 V
  • Rated switching capacity (EF002563): 12.5 kA
  • Short-circuit breaking capacity (Icw) (EF002562): 2 kA
  • Voltage type (EF000187): AC
  • With signal lamp (EF000198): No
  • Max. lamp power (EF000260): 0 W
  • Width in number of modular spacings (EF002950): 3
  • Built-in depth (EF000218): 69.5 mm
  • Degree of protection (IP) (EF005474): IP40
  • Imprint/indication (EF003823): Symbol "arrows"

More info

▲

General specifications

Product Name
Eaton Moeller series IS Disconnector
Catalog Number
276272
Model Code
IS-40/3
EAN
4015082762728
Product Length/Depth
60 mm
Product Height
80 mm
Product Width
53.1 mm
Product Weight
0.305 kg
Compliances
RoHS conform
Certifications
EN45545-2
IEC 61373

Product specifications

Type
IS. Main load disconnector switch
Application
Switchgear for industrial and advanced commercial applications
Degree of protection
IP40
IP10
Terminals
Lift terminal
Equipment heat dissipation, current-dependent
2.2 W
Imprint/indication
Symbol "arrows"
Lamp socket
Other
Ambient operating temperature - max
40 °C
Ambient operating temperature - min
-5 °C
Built-in depth
69.5 mm
Heat dissipation capacity
0 W
Heat dissipation per pole, current-dependent
1.9 W
Lamp power
0 W
Number of contacts (change-over contacts)
0
Number of contacts (normally closed contacts)
3
Amperage rating
40 A
Color calotte
Other
Switch type
Other
Rated short-time withstand current (Icw)
1 kA
Voltage type
AC
Lamp type
Other
Number of contacts (normally open contacts)
3
Rated operational current for specified heat dissipation (In)
40 A
Rated operational voltage (Ue) - max
415 V
Rated switching capacity
12.5 kA
Static heat dissipation, non-current-dependent
0 W
Voltage rating - min
240 V
Width in number of modular spacings
3
Number of poles
Three-pole
