SPCT2-460/4 167611 Y7-167611 EATON ELECTRIC Plug-in surge arresters, 4p, 460VAC, 4x20kA
SPCT2-460/4
167611
Y7-167611
EATON - MOELLER
1 Pcs.
Automation > Surge protection device for power supply systems
Modular Switchgear – Industrial
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
SPCT2-460/4 167611 Y7-167611 EATON ELECTRIC Plug-in surge arresters, 4p, 460VAC, 4x20kA provide robust electrical protection by clamping abnormal voltage spikes and directing them safely to earth. They are widely utilized in industrial power distribution panels to safeguard machinery and internal circuitry from transient overvoltages. Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- System configuration DC (EF009926): No
- System configuration IT (EF009927): Yes
- System configuration TN (EF009928): Yes
- System configuration TN-C (EF009929): No
- System configuration TN-C-S (EF009933): Yes
- System configuration TN-S (EF009930): Yes
- System configuration TT (EF009931): No
- System configuration other (EF009932): Yes
- Number of conductors (without earthing) (EF001148): 4
- Nominal discharge surge current (8/20) (EF004214): 20 kA
- Max. discharge surge current (8/20) (EF012274): 40 kA
- Nominal voltage AC (EF004220): 460 V
- Nominal voltage DC (EF004221): 0 V
- Max. continuous voltage AC (EF004198): 460 V
- Max. continuous voltage DC (EF004777): 0 V
- Max. PV-voltage (EF008795): 0 V
More info
▲General specifications
Delivery program
Technical data - electrical
Technical data - mechanical
Additional information
TN
Other
TN-C-S
TN-S
