SPCT2-460/1 167608 Y7-167608 EATON ELECTRIC Plug-in surge arresters, 1p, 460VAC, 20 kA
SPCT2-460/1
167608
Y7-167608
EATON - MOELLER
1 Pcs.
Automation > Surge protection device for power supply systems
Modular Switchgear – Industrial
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
Eaton Moeller part number SPCT2-460/1 is a plug-in surge arrester designed to clamp and redirect unexpected overvoltages away from valuable electrical machinery. These protective elements are integrated into panel boards to ensure consistent operational safety and equipment longevity. Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- System configuration DC (EF009926): No
- System configuration IT (EF009927): No
- System configuration TN (EF009928): Yes
- System configuration TN-C (EF009929): No
- System configuration TN-C-S (EF009933): No
- System configuration TN-S (EF009930): Yes
- System configuration TT (EF009931): No
- System configuration other (EF009932): Yes
- Number of conductors (without earthing) (EF001148): 1
- Nominal discharge surge current (8/20) (EF004214): 20 kA
- Max. discharge surge current (8/20) (EF012274): 40 kA
- Nominal voltage AC (EF004220): 460 V
- Nominal voltage DC (EF004221): 0 V
- Max. continuous voltage AC (EF004198): 460 V
- Max. continuous voltage DC (EF004777): 0 V
- Max. PV-voltage (EF008795): 0 V
More info
▲General specifications
Delivery program
Technical data - electrical
Technical data - mechanical
Additional information
TN
TN-S
