EATON - MOELLER SPCT2-385 SPCT2-385 167602 Y7-167602 EATON ELECTRIC Surge arrester plug-in unit, 385VAC, 20 kA View larger
Images are for illustrative purposes only. Please refer to data sheet for details

SPCT2-385 167602 Y7-167602 EATON ELECTRIC Surge arrester plug-in unit, 385VAC, 20 kA

SPCT2-385

167602

Y7-167602

EATON - MOELLER

1 Pcs.

Surge arrester plug-in unit, 385VAC, 20 kA SPCT2-385 Eaton Moeller series xPole - SPCT2 Surge Protection Device. Surge arrester plug-in unit, 385VAC, 20 kA For protecting consumer systems against transient overvoltages caused by indirect lightning strikes and switching operations, test class II according to IEC 61643-1+A1, SPD-type T2 according to EN 61643-11, SPC-S-HK auxiliary contact for remote signaling can be added, can be bussed with all Xtra Combinations switchgear

Automation > Surge protection device for power supply systems
Modular Switchgear – Industrial

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Eaton Moeller SPCT2-385 Surge arrester plug-in unit, 385VAC, 20 kA is deployed in industrial and commercial electrical networks to divert transient overvoltages before they reach sensitive automation hardware. These modules are standard elements in panel building, providing reliable suppression against grid fluctuations. Pricing, availability, and lead time are confirmed per enquiry through an RFQ.

  • System configuration DC (EF009926): No
  • System configuration IT (EF009927): No
  • System configuration TN (EF009928): Yes
  • System configuration TN-C (EF009929): No
  • System configuration TN-C-S (EF009933): No
  • System configuration TN-S (EF009930): No
  • System configuration TT (EF009931): No
  • System configuration other (EF009932): Yes
  • Number of conductors (without earthing) (EF001148): 0
  • Nominal discharge surge current (8/20) (EF004214): 20 kA
  • Max. discharge surge current (8/20) (EF012274): 40 kA
  • Nominal voltage AC (EF004220): 385 V
  • Nominal voltage DC (EF004221): 0 V
  • Max. continuous voltage AC (EF004198): 385 V
  • Max. continuous voltage DC (EF004777): 0 V
  • Max. PV-voltage (EF008795): 0 V

More info

▲

General specifications

Product Name
Eaton Moeller series xPole - SPCT2 Surge protection device
Catalog Number
167602
Model Code
SPCT2-385
EAN
4015081640935
Product Length/Depth
47 mm
Product Height
54 mm
Product Width
17.5 mm
Product Weight
0.048 kg
Compliances
RoHS conform

Delivery program

Application
Open areasResidential buildingsUtility buildings
Type
Surge arrester

Technical data - electrical

Voltage protection level
1.8 KV
Voltage protection level (L-N)
0 KV
Voltage protection level (N-PE)
0 KV
Nominal voltage at AC
385 V
Nominal voltage at DC
0 V
Continuous voltage at AC - max
385 V
Continuous voltage at DC - max
0 V
PV-voltage - max
0 V
Nominal discharge surge current (8/20)
20 kA
Discharge surge current (8/20) - max
40 kA
Short-circuit breaking capacity (ISCCR)
0 kA
Signalling at the device
Optic

Technical data - mechanical

Frame
1 modular spacing
Mounting method
On basic element
Number of conductors without earthing
0
Conductor cross section (flexible, fine-strand) - min
0 mm²
Conductor cross section (flexible, fine-strand) - max
0 mm²
Conductor cross section (solid, solid-strand) - min
25 mm²
Conductor cross section (solid, solid-strand) - max
25 mm²
Degree of protection
IP20

Additional information

Features
Category type 2
System configuration type
Other
TN
