SPCT2-335/4 167601 Y7-167601 EATON ELECTRIC Plug-in surge arresters, 4p, 335VAC, 4x20kA
SPCT2-335/4
167601
Y7-167601
EATON - MOELLER
1 Pcs.
Automation > Surge protection device for power supply systems
Modular Switchgear – Industrial
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
Eaton Moeller SPCT2-335/4 plug-in surge arresters are four-pole protective devices utilized in multi-phase power distribution networks to shunt electrical surges safely to ground. They safeguard industrial machinery and commercial installations against transient overvoltages.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- System configuration DC (EF009926): No
- System configuration IT (EF009927): No
- System configuration TN (EF009928): Yes
- System configuration TN-C (EF009929): No
- System configuration TN-C-S (EF009933): Yes
- System configuration TN-S (EF009930): Yes
- System configuration TT (EF009931): No
- System configuration other (EF009932): Yes
- Number of conductors (without earthing) (EF001148): 4
- Nominal discharge surge current (8/20) (EF004214): 20 kA
- Max. discharge surge current (8/20) (EF012274): 40 kA
- Nominal voltage AC (EF004220): 335 V
- Nominal voltage DC (EF004221): 0 V
- Max. continuous voltage AC (EF004198): 335 V
- Max. continuous voltage DC (EF004777): 0 V
- Max. PV-voltage (EF008795): 0 V
