SPCT2-335/2 167599 Y7-167599 EATON ELECTRIC Plug-in surge arresters, 2p, 335VAC, 2x20kA
SPCT2-335/2
167599
Y7-167599
EATON - MOELLER
1 Pcs.
Automation > Surge protection device for power supply systems
Modular Switchgear – Industrial
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
Eaton Moeller SPCT2-335/2 plug-in surge arresters serve as vital protective barriers in low-voltage electrical distribution networks, defending sensitive machinery from lightning-induced voltage surges. Technicians mount these arresters on standard rails inside control cabinets to safely clamp overvoltages before they reach downstream loads.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- System configuration DC (EF009926): No
- System configuration IT (EF009927): No
- System configuration TN (EF009928): Yes
- System configuration TN-C (EF009929): No
- System configuration TN-C-S (EF009933): No
- System configuration TN-S (EF009930): Yes
- System configuration TT (EF009931): No
- System configuration other (EF009932): Yes
- Number of conductors (without earthing) (EF001148): 2
- Nominal discharge surge current (8/20) (EF004214): 20 kA
- Max. discharge surge current (8/20) (EF012274): 40 kA
- Nominal voltage AC (EF004220): 335 V
- Nominal voltage DC (EF004221): 0 V
- Max. continuous voltage AC (EF004198): 335 V
- Max. continuous voltage DC (EF004777): 0 V
- Max. PV-voltage (EF008795): 0 V
