SPCT2-335/1 167598 Y7-167598 EATON ELECTRIC Plug-in surge arresters, 1p, 335VAC, 20 kA
SPCT2-335/1
167598
Y7-167598
EATON - MOELLER
1 Pcs.
Automation > Surge protection device for power supply systems
Modular Switchgear – Industrial
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
Eaton Moeller SPCT2-335/1 is a plug-in surge arrester engineered to shunt damaging electrical overvoltages safely into the grounding system. Facilities utilize these units across distribution boards to prevent premature component wear caused by grid anomalies. Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- System configuration DC (EF009926): No
- System configuration IT (EF009927): No
- System configuration TN (EF009928): Yes
- System configuration TN-C (EF009929): No
- System configuration TN-C-S (EF009933): No
- System configuration TN-S (EF009930): Yes
- System configuration TT (EF009931): No
- System configuration other (EF009932): Yes
- Number of conductors (without earthing) (EF001148): 1
- Nominal discharge surge current (8/20) (EF004214): 20 kA
- Max. discharge surge current (8/20) (EF012274): 40 kA
- Nominal voltage AC (EF004220): 335 V
- Nominal voltage DC (EF004221): 0 V
- Max. continuous voltage AC (EF004198): 335 V
- Max. continuous voltage DC (EF004777): 0 V
- Max. PV-voltage (EF008795): 0 V
