SPCT2-175/4 167591 EATON ELECTRIC Plug-in surge arresters, 4p, 175VAC, 4x20kA
SPCT2-175/4
167591
EATON - MOELLER
1 Pcs.
Automation > Surge protection device for power supply systems
Modular Switchgear – Industrial
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
The Eaton Moeller SPCT2-175/4 plug-in surge arrester provides four-pole transient overvoltage protection for low-voltage power distribution networks. These protective devices are installed in industrial switchboards to limit voltage surges and ensure the continuous, safe operation of electrical loads.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- System configuration DC (EF009926): No
- System configuration IT (EF009927): No
- System configuration TN (EF009928): Yes
- System configuration TN-C (EF009929): No
- System configuration TN-C-S (EF009933): No
- System configuration TN-S (EF009930): No
- System configuration TT (EF009931): No
- System configuration other (EF009932): Yes
- Number of conductors (without earthing) (EF001148): 4
- Nominal discharge surge current (8/20) (EF004214): 20 kA
- Max. discharge surge current (8/20) (EF012274): 40 kA
- Nominal voltage AC (EF004220): 175 V
- Nominal voltage DC (EF004221): 0 V
- Max. continuous voltage AC (EF004198): 175 V
- Max. continuous voltage DC (EF004777): 0 V
- Max. PV-voltage (EF008795): 0 V
